330101-29-52-10-02-05

Bently Nevada 330101-29-52-10-02-05 ClickLoc firikwensin bincike

A kan haja (20 guda), a shirye don aikawa

  • Manufacturer: Bently Nevada

  • Product No.: 330101-29-52-10-02-05

  • Product Type: Sonda Kusanci

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 323g

  • Shipping port: Xiamen

  • Warranty: 12 months

Dokar Mayar da Kaya na Kwanaki 30 · Garantin Watanni 12
  • Isarwa Cikin Gaggawa
  • Tallafi na awa 24 a rana, kwana 7 a mako
  • Tabbacin Inganci

Bayani

Bently Nevada 330101-29-52-10-02-05 3300 XL 8 mm Probe

Bently Nevada 330101-29-52-10-02-05 na’urar bincike ce ta jerin 3300 XL 8 mm tare da zaren 3/8-24 UNF. Yana da tip na PPS, ƙirar TipLoc da CableLoc masu lasisi, ba tare da kariyar ƙarfe (armor) ba.

Siffar Samfuri (Model Configuration)

Sigogi Ƙima
Cikakken Samfuri 330101-29-52-10-02-05 Nau’in Bincike (Probe Type) 3300 XL 8 mm, zaren 3/8-24 UNF, babu kariyar ƙarfe (no armor) Tsawon ɓangaren da ba a yi masa zare ba 29 = 2.9 in Jimillar Tsawon Akwati 52 = 5.2 in Jimillar Tsawo 10 = 1.0 m (3.3 ft) Nau’in Haɗi & Kebul 02 = Ƙananan mahaɗin coaxial ClickLoc, kebul na al’ada Amincewar Hukuma 05 = CSA, ATEX, IECEx

Juriya & Jinkirin DC (Capacitance)

Sigogi Ƙima
Juriya ta DC na bincike (Probe DC Resistance) (1.0m) 7.59 ± 0.50 ohms
Jinkirin lantarki (capacitance) na kebul na tsawo 69.9 pF/m (21.3 pF/ft) na al’ada

Bayani na Jiki (Physical Specifications)

Bangare Kayan / Ƙima
Kayan tip PPS (Polyphenylene sulfide)
Kayan akwati (Case Material) AISI 303 ko 304 Bakin Karfe (Stainless Steel)
Ƙarfin jan kebul 330 N (75 lbf) - ƙirar CableLoc
Nauyi 323 g/m (11.4 oz/m)

Bayani kan Ayyuka (Performance Specifications)

Sigogi Ƙima
Kewayon layi 2 mm (80 mils) daga 0.25 zuwa 2.3 mm
Gibi da ake ba da shawara (Rawar Radial) -9 Vdc (kimanin 1.27 mm / 50 mils)
Ƙimar ma’aunin ƙaruwa (Incremental Scale Factor) (Tsarin 1/5m) 7.87 V/mm (200 mV/mil) ±5%
Ƙimar ma’aunin ƙaruwa (Incremental Scale Factor) (Tsarin 9m) 7.87 V/mm (200 mV/mil) ±6.5%
DSL (Tsarin 1/5m) ±0.025 mm (±1 mil) @ 0°C zuwa +45°C

Wayoyi na filin aiki (Field Wiring)

  • Girman waya: 0.2 zuwa 1.5 mm² (16 zuwa 24 AWG)
  • Shawara: kebul triad mai kariya mai ɗauke da wayoyi 3 masu rufi (shielded) tare da wayoyi masu plating na tin
  • Tsawon da ya fi yawa: 305 m (1,000 ft) tsakanin na’urar Proximitor Sensor da na’urar saka idanu

Kewayon Zazzabi

Yanayi Kewayo
Aikin Bincike na Al’ada -52°C zuwa +177°C (-62°F zuwa +350°F)
Tip ɗin Binciken ETR -52°C zuwa +218°C (-62°F zuwa +425°F)
Kebul & Haɗin ETR -51°C zuwa +260°C (-60°F zuwa +500°F)

Fasalin Zane

  • Ƙirar TipLoc da aka kera ta musamman don ƙarfafa haɗin tip da jikin na’urar
  • Ƙirar CableLoc mai lasisi tare da ƙarfin ja 330 N (75 lbf)
  • Zaɓin kebul ɗin FluidLoc yana hana yayyafar mai ta cikin ciki na kebul
  • Ƙarfen PPS mai kauri don ƙarin ɗorewa
  • Viton® zoben O na hatimin matsin lamba

Takaddun shaida

  • CSA, ATEX, IECEx (Zaɓin Amincewa 05)
  • Mai bin ƙa’idojin FCC Part 15
  • Ummarnin EMC 2014/30/EU
  • Ummarnin RoHS 2011/65/EU

Tambayoyi da ake yawan yi (FAQs)

Q1: Menene daidaitaccen tazarar gibi da ake ba da shawara don rawar radial?
A1: -9 Vdc, kusan 1.27 mm (50 mils) daga abin da ake nufi (target).

Q2: Menene madaidaicin kewayon layi na wannan binciken (probe)?
A2: 2 mm (80 mils) daga 0.25 zuwa 2.3 mm (10 zuwa 90 mils).

Q3: Menene ƙarfin ja na ƙirar CableLoc?
A3: 330 N (75 lbf) don tabbatar da haɗin kebul da tip yadda ya kamata.
