AAI141-H50/K4A00

Yokogawa AAI141-H50/K4A00 16-Channel HART Module

In stock (13 units), ready to be shipped

  • Manufacturer: Yokogawa

  • Product No.: AAI141-H50/K4A00

  • Product Type: Analog Input Module

  • Product Origin: SG

  • Payment:T/T, Western Union

  • Weight: 300g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

Yokogawa AAI141-H50/K4A00 Analog Input Module

The Yokogawa AAI141-H50/K4A00 is a 16-channel analog input module with HART protocol support. This non-isolated module provides efficient 4-20mA signal processing for industrial applications.

Technical Specifications

  • Brand & Model: Yokogawa AAI141-H50/K4A00
  • Product Type: Analog Input Module (4-20mA, Non-Isolated)
  • Input Channels: 16 non-isolated channels
  • Input Signal: 4 to 20 mA DC
  • Update Period: 10 ms data refresh rate

Input Performance

  • Accuracy: ±16 µA measurement precision
  • Allowable Input: Maximum 27 mA current
  • Input Resistance: 400 Ω to 1000 Ω (power ON)
  • Step Response: 100 ms response time

Power & Communication

  • Transmitter Power: 14.8V to 26.4V DC supply
  • Current Consumption: 310 mA (5V DC), 450 mA (24V DC)
  • HART Protocol: Digital communication capability
  • Wire Configuration: 2-wire or 4-wire setting per channel

Connection Interface

  • Interface Adapter: KS Cable Interface Adapter (K4A00)
  • External Connection: Pressure clamp terminal
  • Cable Options: KS cable or MIL connector cable
  • Temperature Drift: ±16 µA per 10°C change

Physical Specifications

  • Weight: 0.3 kg
  • Protection: Standard type with no explosion protection
  • Module Type: Basic type configuration
  • Suffix Code: H indicates HART communication capability

Frequently Asked Questions

  • How many input channels? 16 non-isolated 4-20mA channels.
  • Does it support HART? Yes, includes HART protocol communication.
  • What is the response time? 100 ms step response time.
