TSXDSY16T2 Schneider Electric | 16 Outputs 0.5A 24V PLC Module

In stock (21 units), ready to be shipped

  • Manufacturer: Schneider

  • Product No.: TSXDSY16T2

  • Product Type: Output Module

  • Product Origin: FR

  • Payment:T/T, Western Union

  • Weight: 340g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

Product Overview

The Schneider Electric TSXDSY16T2 is a discrete output module for the Modicon Premium automation platform. It provides 16 solid-state protected outputs at 24V DC positive logic, delivering 0.5A per channel. This module ensures reliable performance for demanding industrial control applications.

Core Functionality

The TSXDSY16T2 drives actuators, relays, and indicators with 16 solid-state outputs. It features electronic tripping for overload and short-circuit protection, a reverse-mounted diode for reverse polarity protection, and transil diodes for overvoltage protection. Response time is just 1.2ms with leakage current below 0.5mA in OFF state. Maximum current per module is 7A with 0.625A per channel.

Technical Specifications

Parameter Value
Part Number TSXDSY16T2
Discrete Outputs 16 (solid-state protected)
Output Voltage 24V DC positive (19-30V)
Output Current per Channel 0.5A (0.625A max)
Total Module Current ≤7A
Response Time 1.2ms
Leakage Current (OFF) ≤0.5mA
Residual Voltage ≤1.2V
Switching Frequency 0.5/LI² Hz
Short-Circuit Protection Electronic tripping (reactivation)
Overvoltage Protection Transil diode
Reverse Polarity Protection Reverse-mounted diode
Dielectric Strength 1500V (50/60Hz, 60s)
Isolation Resistance >10MΩ at 500V
Current Consumption (5V) 80mA
Power Dissipation 1.1W + 0.75W x (outputs x current)
Weight 0.34 kg (0.75 lbs)
Operating Temperature 0°C to 60°C (32°F to 140°F)
Protection Rating IP20
Standards IEC 61131-2, UL 508, CSA
Certifications DNV, GL, BV, ABS, LR, RINA, RMRS

Installation Guide

Mount the TSXDSY16T2 in the Modicon Premium rack. Connect 24V DC power observing positive logic. Wire field devices to the 16 screw terminals. Ensure total module current does not exceed 7A. For inductive loads, use external suppression diodes.

Engineering Advantages

This module delivers comprehensive protection: electronic tripping for short-circuit and overload, transil diode for overvoltage, and reverse-mounted diode for polarity errors. Fast 1.2ms response supports real-time control. Multiple marine certifications (DNV, GL, BV, ABS, LR) qualify it for shipboard applications. At 0.34 kg, it minimizes chassis loading.
