TSXDSY08R5A

Schneider TSXDSY08R5A 8 Relay Output Module 5A 24-240V

In stock (11 units), ready to be shipped

  • Manufacturer: Schneider

  • Product No.: TSXDSY08R5A

  • Product Type: Output Module

  • Product Origin: FR

  • Payment:T/T, Western Union

  • Weight: 420g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

Schneider Electric TSXDSY08R5A TSX Micro PLC Discrete Output Module

Schneider Electric TSXDSY08R5A is a discrete output module for TSX Micro PLCs with 8 relay-protected outputs. Supports 24-48V DC and 24-240V AC, 5A thermal current, and features RC circuit overvoltage protection.

Key Specifications

Parameter Value
Part Number TSXDSY08R5A
Series TSX Micro PLC
Product Type Discrete Output Module
Output Count 8
Output Type Relay Protected
Contact Configuration 2 x 2 C/O + 2 x 2 NO
Output Voltage (DC) 24-48V DC (19-60V)
Output Voltage (AC) 24-240V AC (20-264V)
Thermal Current 5A
Response Time < 10ms ON / < 15ms OFF
Current Consumption 80mA @ 24V DC / 55mA @ 5V DC
Weight 0.42 kg (0.93 lb)

Protection Features

Protection Type Specification
Overvoltage Protection RC Circuit and Ge-Mov
Overload Protection 6.3A interchangeable fuse per common
Short-Circuit Protection 6.3A interchangeable fuse per common
Isolation Resistance > 10MΩ at 500V
Dielectric Strength 2000V 50/60Hz for 60s

Electrical Durability

  • 1,000,000 cycles DC-12 (24W @ 24V / 50W @ 48V Resistive)
  • 1,000,000 cycles DC-3 (24W @ 24V / 50W @ 48V Inductive)
  • 1,000,000 cycles AC-12 (100VA @ 48V / 220VA @ 100-120V / 440VA @ 220-240V Resistive)
  • 1,000,000 cycles AC-14/AC-15 (220VA @ 220-240V Inductive)
  • 10,000,000 cycles AC-14/AC-15 (20VA @ 100-120V / 220-240V Inductive)

Environmental Specifications

Parameter Value
Operating Temperature 0°C to +60°C (32°F to 140°F)
Storage Temperature -25°C to +70°C (-13°F to 158°F)
Humidity (Operation) 10-95% non-condensing
Protection Class IP20
Pollution Degree 2

Certifications

  • CE Marked (73/23/EEC, 89/336/EEC, 92/31/EEC, 93/68/EEC)
  • UL 508
  • CSA C22.2 No 142, No 213 (Class I Division 2 Groups A, B, C, D)
  • IEC 61131-2
  • ABS, RINA, GL, DNV, RMRS, LR, BV

FAQs

Q1: How many outputs does the TSXDSY08R5A have?
A1: 8 relay-protected outputs with 2 x 2 C/O and 2 x 2 NO contacts.

Q2: What voltage ranges does this module support?
A2: 24-48V DC and 24-240V AC.

Q3: What is the response time?
A3: Less than 10ms activation and less than 15ms deactivation.
