140CRP93100

Schneider 140CRP93100 RIO Head-End Module

In stock (16 units), ready to be shipped

  • Manufacturer: Schneider

  • Product No.: 140CRP93100

  • Product Type: Adaptor Module

  • Product Origin: FR

  • Payment:T/T, Western Union

  • Weight: 450g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

Schneider Electric Modicon Quantum 140CRP93100 RIO Head-End Adaptor Module

The 140CRP93100 is a remote I/O (RIO) head-end adaptor module from the Schneider Electric Modicon Quantum automation platform. This module features a single coaxial cable connection with an F-type elbowed female connector. It supports up to 31 drops per network with 64 I/O words per drop at 1.544 Mbit/s transmission rate.

Key Features

  • RIO head-end adaptor module for Modicon Quantum systems
  • Single cable connection with F-type elbowed female connector
  • Supports up to 31 drops per network
  • 64 I/O words per drop (64 input + 64 output words)
  • Transmission rate: 1.544 Mbit/s
  • Cable type: 75 ohm coaxial with 35 dB dynamic range
  • Isolation voltage: 500 V DC (coaxial center to ground)
  • Compatible with Quantum 200/500/800 series and Symax (any mix)
  • Diagnostics: LAN controller check, memory check, power-up test
  • FM Class 1 Division 2 certified

Technical Specifications

  • Brand: Schneider Electric
  • Series: Modicon Quantum
  • Model: 140CRP93100
  • Product Type: RIO Head-End Adaptor Module
  • Connector: 1 female F-type elbowed with single cable
  • Transmission Rate: 1.544 Mbit/s
  • Drops per Network: ≤ 31
  • I/O Words per Drop: 64 input / 64 output words
  • Cable Type: 75 ohm coaxial
  • Dynamic Range: 35 dB
  • Isolation Voltage: 500 V DC (coaxial center to ground)
  • Power Dissipation: 3 W (1 channel)
  • Bus Current Requirement: 600 mA (1 channel)
  • Module Format: Standard
  • CE Marking: Yes

Environmental Specifications

  • Operating Temperature: 0 to 60°C
  • Storage Temperature: -40 to 85°C
  • Relative Humidity: 95% without condensation
  • Operating Altitude: ≤ 5000 m
  • Resistance to Electrostatic Discharge: 4 kV contact, 8 kV air (IEC 801-2)
  • Resistance to Electromagnetic Fields: 10 V/m 80-1000 MHz (IEC 801-3)

Package Includes

  • 1x Schneider Electric 140CRP93100 RIO head-end adaptor module
  • 1x installation documentation

FAQ

1. What is the part number for this RIO head-end adaptor?

The part number is 140CRP93100.

2. How many drops and I/O words does the 140CRP93100 support?

It supports up to 31 drops per network with 64 input and 64 output words per drop.

3. What type of cable and transmission rate does this module use?

It uses 75 ohm coaxial cable with a transmission rate of 1.544 Mbit/s and 35 dB dynamic range.
