GE Fanuc IC670GBI001 Genius Bus Interface Unit Panel Mount

GE Fanuc IC670GBI001 Genius Bus Interface Unit

The GE Fanuc IC670GBI001 is a Genius Bus Interface Unit. It is designed for the Field Control I/O system. This unit manages communication between the Genius bus and I/O modules. It provides stable power and diagnostics for reliable system operation.

Technical Specifications

• Brand GE Fanuc
• Model IC670GBI001
• Type Genius Bus Interface Unit (BIU)
• Nominal Voltage 115 VAC or 125 VDC
• Voltage Range 90–135 VAC / 105–150 VDC
• Input Frequency 47–63 Hz (for AC input)
• Power AC 48 VA at 115V AC full load
• Power DC 24 Watts at 125V DC full load
• Inrush Current 20 Amps peak (3 ms maximum)
• DC Output 6.5 Volts DC
• Holdup Time 20 milliseconds maximum
• LED Indicators PWR, OK, RUN, BUS B
• HHM Port Hand-Held Monitor interface connector
• Memory Configuration stored in terminal block
• Enclosure Corrosion-resistant aluminum housing
• Mounting Panel-mount design
• Operating Temp 0 to 60°C (32 to 140°F)
• Storage Temp -40 to 85°C (-40 to 185°F)
• Humidity 5% to 95% non-condensing

Key Features

• Dual Voltage Input Accepts both AC and DC power sources
• Robust Enclosure Durable aluminum housing for industrial use
• Diagnostic LEDs Four status indicators for quick fault finding
• HHM Interface Dedicated port for Hand-Held Monitor connection
• Backplane Power Supplies logic power to connected I/O modules
• Configuration Memory Stores setup data in terminal block
• Wide Temp Range Reliable operation in harsh environments

Installation Guide

• Panel-mount the IC670GBI001 unit in your control cabinet.
• Connect the main power (115VAC or 125VDC) to the designated terminals.
• Wire the Genius bus communication cable to the BUS B port.
• Connect the I/O module backplane to receive 6.5VDC logic power.
• Use the HHM port for initial configuration and troubleshooting.
• Observe the PWR, OK, RUN, and BUS B LEDs for system status.

Packaging & Shipping

• One IC670GBI001 Genius Bus Interface Unit
• Mounting hardware and installation guide
• Product specification documentation
• International shipping via FedEx, UPS, and DHL available

Frequently Asked Questions

What power sources can the IC670GBI001 use?

The unit can use either 115 Volts AC or 125 Volts DC as its primary input power source.

What is the purpose of the DC output voltage?

It provides 6.5 Volts DC to power the logic circuits of the connected Field Control I/O modules on the backplane.

How do I monitor the status of this interface unit?

Monitor the four LED indicators: PWR (power), OK (system health), RUN (operation), and BUS B (bus communication).
