Delta DOP-107CV 7-Inch HMI | IP65 Industrial Touchscreen

Delta DOP-107CV HMI Touchscreen Introduction

The DOP-107CV provides a reliable 7-inch touchscreen solution for industrial control applications. This compact HMI delivers clear visualization with its high-brightness display and robust construction. The unit's IP65 rating ensures dependable operation in challenging industrial environments where dust and moisture protection is essential.

Key Technical Specifications

• Brand: Delta
• Model Name: DOP-107CV
• Series: DOP-100 Series
• Display Size and Type: 7-inch TFT LCD
• Display Colors: 16-bit (65,536 colors)
• Resolution: 800 x 480 pixels
• Luminance: 400 cd/m²
• Processor: ARM Cortex-A8 800 MHz
• Flash Memory: 256 MB
• RAM: 256 MB
• USB Ports: 1 USB Slave, 1 USB Host (v2.0)
• Communication Ports: COM1 RS-232, COM2 RS-232/485, COM3 RS-422/485
• Power Consumption: 8.5 Watts
• IP Rating: IP65 / NEMA4 / UL Type 4X
• Dimensions: 8.46" x 6.33" x 2.4"
• Weight: 1.7 kilograms (3.75 pounds)

Environmental Protection Features

• IP65 front panel rating protects against dust and water jet sprays
• NEMA4 certification ensures reliable operation in industrial settings
• UL Type 4X approval validates performance in corrosive environments
• Robust housing withstands vibration and mechanical stress in factories
• Sealed construction prevents contamination from oils and coolants

Connectivity and Control Functions

• Three communication ports support multiple industrial protocols
• Hardware flow control ensures reliable data transmission integrity
• Dual USB interfaces facilitate programming and peripheral expansion
• Efficient 8.5W power design reduces overall system energy costs
• Compact dimensions allow installation in space-limited control panels

Frequently Asked Questions (FAQ)

• What environmental protection does this HMI offer? IP65 front panel rating for dust and water resistance
• How many communication ports are available? Three COM ports supporting multiple serial protocols
• What is the display brightness level? 400 cd/m² for clear viewing in bright industrial areas
