288055-01

Bently Nevada 3500/22M TDI Module 288055-01 Monitoring Systems

In stock (22 units), ready to be shipped

  • Manufacturer: Bently Nevada

  • Product No.: 288055-01

  • Product Type: Transient Data Interface Module

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 910g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

Bently Nevada 3500/22M: Transient Data Interface Module

The Bently Nevada 288055-01 module captures critical transient data. This TDI module connects to 3500 monitoring systems. It provides USB and Ethernet communication interfaces. The unit supports reliable data acquisition and transfer.

Key Specifications

  • Model: 288055-01 Standard TDI Module
  • Product Type: 3500/22M Transient Data Interface
  • Interface: USB cable and 10Base-T/100Base-TX I/O
  • Fiber Option: 100Base-FX I/O capability available
  • Weight: 0.91 kg (2.0 lbs) total module weight

Battery Performance

  • Powered Operation: Up to 38 years at 50°C (122°F)
  • Unpowered Standby: Up to 12 years at 50°C (122°F)
  • Longevity: Exceptional battery life for continuous monitoring

Operating Conditions

  • Temperature: -30°C to +65°C (-22°F to +149°F)
  • Storage Temp: -40°C to +85°C (-40°F to +185°F)
  • Humidity: Up to 95% non-condensing maximum

Physical Dimensions

  • Size: 241.3 mm x 24.4 mm x 241.8 mm
  • Imperial: 9.50 in x 0.96 in x 9.52 in
  • Weight: 0.91 kg (2.0 lbs) total weight

Communication Features

  • USB Interface: Direct connection for data transfer
  • Ethernet Port: 10Base-T/100Base-TX network capability
  • Fiber Optic: Optional 100Base-FX interface available
  • Data Capture: Transient event recording and storage

Packaging Contents

  • One (1) 288055-01 TDI Module
  • One (1) USB connection cable
  • Installation and configuration documentation
  • Mounting hardware for rack installation

Installation Guidelines

  • Install in compatible 3500 series monitoring rack
  • Connect USB cable for direct computer interface
  • Configure Ethernet settings for network access
  • Ensure adequate ventilation around the module
  • Verify all connections before power application

Frequently Asked Questions

What is the main function of this module?

  • The 288055-01 captures and transfers transient data from 3500 monitoring systems via USB/Ethernet.

What communication interfaces does it support?

  • It provides USB, 10Base-T/100Base-TX Ethernet, and optional 100Base-FX fiber interfaces.

What is the operating temperature range?

  • The module operates from -30°C to +65°C (-22°F to +149°F).
