X20PS3310

B&R X20PS3310 Integrated Fuse Module

In stock (12 units), ready to be shipped

  • Manufacturer: B&R

  • Product No.: X20PS3310

  • Product Type: I/O Module

  • Product Origin: AT

  • Payment:T/T, Western Union

  • Weight: 500g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

B&R X20PS3310 X2X Link & I/O Power Supply with Integrated Fuse

B&R X20PS3310 powers both X2X Link communication and internal I/O supply. Features integrated replaceable fuse for I/O and isolated bus feed with redundancy support. Engineered for PPC2100, PPC2200, and link module systems.

X2X Link Power Supply

  • Input voltage: 24 VDC -15% / +20%
  • Input current: Max. 0.7 A
  • Integrated non-replaceable fuse
  • Reverse polarity protection: Yes
  • Nominal output power: 7 W
  • Parallel connection and redundant operation supported
  • Short-circuit proof with temporary overload protection

I/O Power Supply

  • Input voltage: 24 VDC -15% / +20%
  • Input current: Max. 6 A
  • Integrated fuse: 6.3 A, slow-blow, replaceable
  • No reverse polarity protection
  • Nominal output voltage: 24 VDC
  • Permissible contact load: 6 A
  • On short circuit: Integrated fuse protects system

Electrical Isolation

  • X2X Link supply isolated from X2X Link power supply
  • I/O supply not isolated from I/O power supply

Status & Diagnostics

  • B&R ID code: 0x2017
  • Status indicators for overload, operating state, module status
  • Diagnostics via LED and software
  • Power consumption: 1.42 W (X2X Link), 0.82 W (internal I/O)

Certifications

  • CE, UKCA, CRA in preparation
  • ATEX Zone 2: II 3G Ex nA nC IIA T5 Gc
  • UL: cULus E115267, HazLoc Class I Div 2 Groups ABCD T5
  • KC approved

Mounting & Environment

  • Horizontal or vertical mounting orientation
  • Operation temp: -25 to 60°C (horizontal), -25 to 50°C (vertical)
  • Storage/transport temp: -40 to 85°C
  • Relative humidity: 5 to 95%, non-condensing
  • IP20 protection per EN 60529

Installation Guidelines

  • 0 to 2000 m elevation: No limitation
  • >2000 m: Reduce ambient temp by 0.5°C per 100 m

Required Components

  • Order terminal block X20TB12 separately
  • Order power supply bus module X20BM01 separately
  • Pitch: 12.5+0.2 mm

Package Includes

  • B&R X20PS3310 supply module unit
  • Documentation and quick start guide

Shipping

  • FedEx, UPS, DHL worldwide with tracking

FAQ

How do I replace the I/O fuse?

Open module and replace with 6.3 A slow-blow fuse only.

Can I run redundant X2X Link supplies?

Yes. The X20PS3310 supports parallel redundant operation.

Is the X2X Link output isolated?

Yes. Full electrical isolation for X2X Link supply.
