3BSE021443R1

ABB TU843 50V Terminal Unit | Vertical Mounting

In stock (31 units), ready to be shipped

  • Manufacturer: ABB

  • Product No.: 3BSE021443R1

  • Product Type: Terminal Block

  • Product Origin: SE

  • Payment:T/T, Western Union

  • Weight: 600g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

Product Overview

The ABB TU843 terminal block delivers reliable 16-channel connection for industrial automation. This vertical-mount unit belongs to the Advant-800xA series. The TU843 provides secure signal interface in demanding control systems.

Product Identification

  • Manufacturer: ABB
  • Model Number: TU843
  • Article Number: 3BSE021443R1
  • Product Series: Advant-800xA
  • Connection Type: 16-channel terminal block

Electrical Specifications

  • Voltage Rating: 50V operating voltage
  • Channel Current: 3A maximum per I/O channel
  • Process Current: 10A maximum for process connection
  • Process Power: 20V range (0V to 20V)
  • Dielectric Strength: 500V AC test voltage

Mechanical & Installation Features

  • Mounting Style: Vertical orientation installation
  • Wire Sizes: Solid wire: 0.2-4 mm²
  • Wire Compatibility: Stranded: 0.2-2.5 mm² (24-12 AWG)
  • Installation Torque: 0.5-0.6 Nm recommended setting
  • Stripping Length: Prepare 7 mm of wire insulation

Physical Dimensions

  • Unit Weight: 0.6 kg (1.3 lbs)
  • Width: 131 mm (5.16 inches)
  • Depth: 64 mm (2.52 inches)
  • Height: 186.5 mm (7.34 inches)
  • Compact Design: Space-efficient terminal block

Environmental Specifications

  • Operating Temperature: 0°C to +55°C (32°F to 131°F)
  • Storage Range: -40°C to +70°C (-40°F to 158°F)
  • Humidity Range: 5% to 95% RH, non-condensing
  • Protection Rating: IP20 (IEC 60529)
  • Pollution Degree: Degree 2 per IEC 60664-1

Compliance & Standards

  • EMC Standards: EN 61000-6-4, EN 61000-6-2
  • Mechanical Standard: IEC/EN 61131-2
  • Overvoltage Category: IEC/EN 60664-1
  • RoHS Compliance: Yes, meets EN 50581:2012
  • WEEE Directive: 2012/19/EU compliant

FAQ

  • What system is the TU843 designed for?
  • This terminal block works with ABB's Advant-800xA automation series.
  • How many connections does this terminal block provide?
  • The TU843 offers 16 individual channels for wiring connections.
  • What is the main mounting orientation?
  • This unit is designed for vertical mounting in control cabinets.
