330905-01-08-10-01-00 Bently Nevada Proximity Probe 10mm 80mm

The Bently Nevada 330905-01-08-10-01-00 is a 3300 NSv Proximity Probe with connector protector for industrial vibration monitoring. It features M10X1 threads with 1.0m standard cable and no agency approvals.

Product Details

• Part Number: 330905-01-08-10-01-00
• Model: 3300 NSv Proximity Probe
• Manufacturer: Bently Nevada
• Weight: 14-150 g (0.5-5.3 oz)

Configuration

• Thread Type: M10X1, without armor
• Unthreaded Length: 10 mm
• Case Length: 80 mm
• Cable Length: 1.0 meter (39 in)
• Connector: Miniature coaxial ClickLoc with connector protector, standard cable
• Approval: Not required (00)

Electrical Specifications

• DC Resistance: 4.2 ± 0.5 ohms at 1.0m
• Linear Range: 1.5 mm (60 mils) from 0.25 to 1.75 mm
• Recommended Gap: 1.0 mm (40 mils)
• Scale Factor: 7.87 V/mm (200 mV/mil) +12.5%/-20%
• Deviation: Less than ±0.06 mm (±2.3 mils)
• Output: -1 to -13 Vdc
• Frequency Response: 0-10 kHz: +0, -3 dB typical

Extension Cable

• DC Resistance: Center 0.220 Ω/m, Shield 0.066 Ω/m
• Capacitance: 69.9 pF/m typical

Mechanical Specifications

• Tip Material: Polyphenylene sulfide (PPS)
• Case Material: AISI 304 stainless steel
• Cable: 75 Ω coaxial, FEP insulated
• Min Bend Radius: 25.4 mm (1.0 in)
• Seal: Viton O-ring

Field Wiring

• Wire Size: 0.2-1.5 mm² (16-24 AWG)
• With Ferrules: 0.25-0.75 mm² (18-23 AWG)

Package

• One 330905-01-08-10-01-00 proximity probe with connector protector
• Factory original packaging
• Documentation included

Shipping

• Worldwide via FedEx, UPS, DHL
• Secure packaging guaranteed

FAQs

• What is the unthreaded length of this probe?
  The 330905-01-08-10-01-00 has a 10 mm unthreaded length and 80 mm case length.
• What is the connector type?
  This probe features a ClickLoc connector with protector for enhanced durability.
• Does this probe have agency approvals?
  No, this configuration has no agency approvals (Option 00).
