330101-00-20-05-01-05

3300 XL 8mm Proximity Probe Bently Nevada 330101-00-20-05-01-05

In stock (12 units), ready to be shipped

  • Manufacturer: Bently Nevada

  • Product No.: 330101-00-20-05-01-05

  • Product Type: 3300 XL 8 mm Proximity Probe

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 323g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

Bently Nevada 330101-00-20-05-01-05 3300 XL 8 mm Proximity Transducer Probe

The Bently Nevada 330101-00-20-05-01-05 is a 3300 XL 8 mm proximity probe for machinery vibration, position, and speed monitoring. Engineered with a 3/8-24 UNF thread, 2.0-inch overall case length (0.0-inch unthreaded length), 0.5-meter (1.6 ft) miniature coaxial cable, and ClickLoc connector with terminal protector, this probe features a linear density weight of 323 g/m (11.4 oz/ft) to ensure structural stability without adding unnecessary mass. Constructed with stainless steel and PPS plastic encapsulation, it provides non-contact displacement measurement across a 2.0 mm (80 mil) linear range while utilizing patented TipLoc and CableLoc technologies to deliver maximum mechanical strength and environmental resistance in hazardous industrial applications.

Technical Specifications

Brand / Manufacturer Bently Nevada / Baker Hughes
Complete Part Number 330101-00-20-05-01-05
Product Family / System 3300 XL 8 mm Proximity Transducer System
Thread Option & Case Thread 3/8-24 UNF Thread [Option -01]
Unthreaded / Total Case Length Unthreaded Length: 0.0 in [Option -00] | Overall Case Length: 2.0 in [Option -20]
Total Cable Length & Weight 0.5 meter (1.6 feet) [Option -05] | Weight: 323 g/m (11.4 oz/ft)
Connector Type & Approval Miniature Coaxial ClickLoc Connector w/ Protector [Option -01] | Multiple Approvals [Option -05]
Linear Range & Scale Factor 0.25 to 2.3 mm (10 to 90 mils) | 7.87 V/mm (200 mV/mil) ±5%
Electrical Characteristics DC Resistance: 7.45 ± 0.50 Ω | Cable Capacitance: 69.9 pF/m (21.3 pF/ft)
Mechanical Pull & Pressure Rating 330 N (75 lbf) Cable Pull Strength | 10 bar (145 psi) Differential Pressure Seal
Operating Temperature Range Probe Tip: -52°C to +218°C (-62°F to +425°F) | Cable: -51°C to +260°C (-60°F to +500°F)
Hazardous Area Certifications CSA, ATEX, IECEx Approved for Class I, Div 1/Zone 0 Intrinsic Safety

Quick Installation Guide

  • Mount the probe into the threaded machine port (3/8-24 UNF) and adjust the gap setting using a feeler gauge or Proximitor sensor output voltage.
  • Torque the probe locknut securely to prevent mechanical loosening under high machine vibration.
  • Connect the 0.5 m probe cable to the matching 3300 XL extension cable using the ClickLoc connector and snap the connector protector over the junction.
  • Ensure the total system cable length matches the Proximitor sensor calibration (e.g., 5-meter or 9-meter overall system).

Technical FAQs

Q1: What does the option code break down for 330101-00-20-05-01-05 mean?
A1: 330101 (3/8-24 UNF probe), -00 (0.0 in unthreaded length), -20 (2.0 in case length), -05 (0.5 m cable length), -01 (ClickLoc connector with protector), -05 (Multiple hazardous area approvals).

Q2: Why is the ClickLoc connector protector important?
A2: It prevents moisture and contaminant ingress at the probe-to-extension cable connection while ensuring lock security against machine vibration.

Q3: Can this probe be used with 5-meter and 9-meter 3300 XL Proximitor systems?
A3: Yes, provided it is paired with the appropriate length 3300 XL extension cable to maintain the total matched system length required by the Proximitor sensor.
