330103-00-12-05-12-05 Hazardous Area Probe Bently Nevada

Bently Nevada 330103-00-12-05-12-05 Vibration Probe

The Bently Nevada 330103-00-12-05-12-05 monitors machinery vibration. This 8mm probe has 0.5m FluidLoc cable. It operates from -52°C to +177°C temperature range.

Core Specifications

• Part Number: 330103-00-12-05-12-05
• Tip Diameter: 8 mm PPS material
• Cable Length: 0.5 meters FluidLoc type
• Unthreaded Length: 12 mm
• Mounting Thread: M10x1

Electrical Specifications

• DC Resistance: 7.45 Ω ±0.50 at 0.5m
• Gap Setting: 1.27 mm optimal at -9 V DC
• Sensing Range: 0.25 to 2.3 mm
• Field Wiring: Supports up to 305 meters

Mechanical Specifications

• Thread Engagement: 15 mm maximum
• Case Material: AISI 303/304 stainless
• Weight per Meter: 323 g/m (11.4 oz/ft)
• Connector Type: ClickLoc miniature coaxial
• Seal Type: Viton O-ring design

Environmental Specifications

• Temperature Range: -52°C to +177°C
• Cable Temperature: Up to +260°C extended
• Humidity Resistance: IEC 68-2-3 compliant
• Minimum Temperature: Avoid below -34°C
• Humidity Variation: <3% ASF after 56 days

Certifications

• Safety Certifications: CSA ATEX IECEx FM
• Additional Approvals: GOST-R NEPSI
• Hazardous Area: Class I Zone 0 rated
• Division Rating: Class I Div 2 approved

Application Specifications

• Target Gap: 1.27 mm (50 mils) optimal
• Measurement Range: 0.25-2.3 mm (10-90 mils)
• Industrial Use: Harsh environment suitable
• Installation: Proper gap setting required

Package Contents

• 330103-00-12-05-12-05 probe unit
• FluidLoc cable assembly
• Certification documentation
• Shipping Weight: Approximately 0.3 kg
• FedEx UPS DHL shipping options

FAQ

What is the cable length of the 330103-00-12-05-12-05?

The 330103-00-12-05-12-05 has a 0.5 meter FluidLoc cable.

What temperature range does this probe support?

This probe operates from -52°C to +177°C.

What certifications does it have?

Certified for CSA, ATEX, IECEx, FM, GOST-R, and NEPSI standards.
