TSXPSY5500M

Schneider Electric TSXPSY5500M 50W Power Supply Module

A kan haja (17 guda), a shirye don aikawa

  • Manufacturer: Schneider

  • Product No.: TSXPSY5500M

  • Product Type: Power Supply

  • Product Origin: FR

  • Payment:T/T, Western Union

  • Weight: 620g

  • Shipping port: Xiamen

  • Warranty: 12 months

Dokar Mayar da Kaya na Kwanaki 30 · Garantin Watanni 12
  • Isarwa Cikin Gaggawa
  • Tallafi na awa 24 a rana, kwana 7 a mako
  • Tabbacin Inganci

Bayani

Schneider Electric TSXPSY5500M Power Supply Module

Product Overview

Schneider Electric TSXPSY5500M is a power supply module for TSX Micro PLCs. It operates on 200-240V AC or 100-120V AC input at 50/60Hz. Delivers 50W total useful secondary power. Outputs 35W at 5V DC and 19W at 24V DC. Features comprehensive protection and three LED status indicators. Made in France.

Technical Specifications

Parameter Value
Brand Schneider Electric
Model TSXPSY5500M
Series TSX Micro PLCs
Type Power Supply Module
Primary Voltage 100 120V AC (85 140V) / 200 240V AC (190 264V)
Network Frequency 50/60 Hz (47 63 Hz limits)
Input Current 1700 mA at 100V / 500 mA at 240V
Inrush Current 38 A at 100V / 38 A at 240V
Total Secondary Power 50 W
Secondary Power 5V 35 W (7 A at 5V DC)
Secondary Power 24V 19 W (0.8 A relay / 0.8 A sensor)
Protection Internal fuse 4A, overload, overvoltage, short circuit
Insulation Resistance ≥ 100 MOhm
Local Signalling 2 Green LEDs, 1 Red LED
Operating Temperature 0°C to +60°C
Storage Temperature 25°C to +70°C
Humidity 10% to 95% non condensing
Operating Altitude 0 to 2000 meters
Protection Class IP20
Pollution Degree 2
Marking CE
Weight 0.62 kg
Country of Origin France

Installation

Mount module in TSX Micro PLC rack. Connect 100 120V AC or 200 240V AC primary power. Verify input current: 1700mA at 100V or 500mA at 240V. Green LEDs indicate voltage presence and sensor voltage. Red LED indicates battery fault. Operating temperature 0°C to +60°C. IP20 protection.

Features

50W total useful secondary power. Dual outputs: 35W at 5V DC (7A) and 19W at 24V DC (0.8A relay and sensor). Internal 4A time delayed fuse. Overload, overvoltage, and short circuit protection. Three LED status indicators. Dielectric strength 2000V. Marine certifications: ABS, BV, DNV, GL, LR, RINA, RMRS.

FAQ

Q1: What input voltages are accepted?
A1: 100 120V AC (85 140V) or 200 240V AC (190 264V) at 50/60Hz. Network frequency limits 47 63Hz.

Q2: What is the total secondary power output?
A2: 50W total. Divided as 35W at 5V DC (7A) and 19W at 24V DC (0.8A relay power and 0.8A sensor power).

Q3: What do the LED indicators mean?
A3: Green LED for voltage presence (OK). Green LED for sensor voltage (24V). Red LED for battery fault (BAT).
