330101-01-13-05-01-00

Proximity Probe 330101-01-13-05-01-00 Bently Nevada 8mm

Ragowar raka'a 9 kaɗai

  • Manufacturer: Bently Nevada

  • Product No.: 330101-01-13-05-01-00

  • Product Type: 3300 XL 8 mm Probe

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 323g

  • Shipping port: Xiamen

  • Warranty: 12 months

Dokar Mayar da Kaya na Kwanaki 30 · Garantin Watanni 12
  • Isarwa Cikin Gaggawa
  • Tallafi na awa 24 a rana, kwana 7 a mako
  • Tabbacin Inganci

Bayani

Bently Nevada 330101-01-13-05-01-00 3300 XL 8mm Proximity Probe

Product Overview

Bently Nevada 330101-01-13-05-01-00 is a 3300 XL 8mm proximity probe with standard 3/8-24 UNF thread. Features TipLoc and CableLoc designs for robust mechanical integrity. 1.3 inch case length with 0.5 meter total length. IP67 sealed ClickLoc connector with 15kV ESD protection. Certified for hazardous locations with ATEX and IECEx approvals.

Model Number Decoder

Position Code Meaning
1 3 330101 3300 XL 8mm Probe, 3/8-24 UNF, without armor
4 01 Unthreaded Length 0.1 inch
5 6 13 Overall Case Length 1.3 inch
7 8 05 Total Length 0.5 meter
9 10 01 ClickLoc connector with connector protector
11 12 00 No agency approval

Technical Specifications

Parameter Value
Brand Bently Nevada
Model 330101-01-13-05-01-00
Type 3300 XL 8mm Proximity Probe
Thread 3/8-24 UNF
Tip Material Polyphenylene sulfide (PPS)
Case Material AISI 303/304 SST
Unthreaded Length 0.1 inch
Case Length 1.3 inch
Total Length 0.5 meter (1.6 feet)
Connector ClickLoc with connector protector
Connector Rating 500+ mating cycles, IP67 sealed
ESD Protection 15kV
Linear Range 2 mm (80 mils)
Sensitivity 7.87 V/mm (200 mV/mil) ±5%
DC Resistance 7.45 Ω ±0.50
TipLoc Pull Strength 330 N (75 lbf)
Case Torque Max 33.9 N•m (300 in•lbf)
Recommended Torque 11.2 N•m (100 in•lbf)
Operating Temp 52°C to +177°C
Storage Temp 52°C to +177°C
Humidity Tolerance ≤3% ASF change at 93% RH
Vibration Resistance 5G (10 2000Hz)
Weight 323 g/m (11.4 oz)

Installation

Mount probe with 3/8-24 UNF threaded case. Recommended gap for radial vibration is 9 VDC (1.27mm / 50 mils). Tighten case to 11.2 N•m (100 in•lbf). Finger tighten ClickLoc connectors until click. Do not exceed 0.565 N•m (5 in•lbf) connector torque. Allow 25.4mm (1.0 in) minimum cable bend radius.

Features

TipLoc molding provides 330N pull strength. CableLoc design secures cable to probe body. IP67 sealed ClickLoc connectors with 500+ mating cycles. 15kV ESD protection. PPS tip withstands corrosive environments. Meets API 670 Standard for mechanical configuration and temperature stability. Backward compatible with non-XL 3300 5mm and 8mm components.

FAQ

Q1: What is the recommended gap setting for radial vibration?
A1: 9 VDC equals approximately 1.27mm (50 mils) for optimal linear range. Use this as starting point for installation.

Q2: How tight should connectors be?
A2: Finger tighten ClickLoc connectors until you hear and feel a click. Do not use tools. Maximum torque is 0.565 N•m (5 in•lbf).

Q3: Is this probe compatible with existing 3300 series?
A3: Yes. 3300 XL 8mm components are electrically and physically interchangeable with non-XL 3300 5mm and 8mm components when minimum cable bend radius is observed.
