IC695CRH035

Original Stock GE Fanuc IC695CRH035 Series 90-70 to RX3i Harness

A kan haja (13 guda), a shirye don aikawa

  • Manufacturer: General Electric

  • Product No.: IC695CRH035

  • Product Type: Harness Assembly

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 500g

  • Shipping port: Xiamen

  • Warranty: 12 months

Dokar Mayar da Kaya na Kwanaki 30 · Garantin Watanni 12
  • Isarwa Cikin Gaggawa
  • Tallafi na awa 24 a rana, kwana 7 a mako
  • Tabbacin Inganci

Bayani

GE Fanuc IC695CRH035 Harness Assembly

The GE Fanuc IC695CRH035, also cataloged as the IC695CRH035 Harness Assembly, operates as a dedicated wiring interface for migrating Series 90-70 ALG320 field wiring to PACSystems RX3i ALG708 analog modules.

Hardware Specifications

Parameter Specification
Model IC695CRH035
Brand GE Fanuc
Product Type Harness Assembly
Source Module IC697ALG320 (Series 90-70)
Target Module IC695ALG708 (RX3i)
Input Channels 16 differential voltage inputs
Input Signal Range ±10 V
Maximum Expander Modules 7 daisy-chained
Maximum Total Inputs 120
Compatibility IC695ACC651 I/O Adapter, Series 90-70 terminal blocks

Field Installation Guidelines

Install the IC695ACC651 I/O Adapter Card in the RX3i universal backplane. Connect the IC695CRH035 harness between the adapter card and existing Series 90-70 field terminal blocks. Verify CPU firmware version is 3.0 or later before commissioning. Confirm pin mapping against the module wiring diagram before applying field signals. Route harness wiring away from high-current power conductors. Ground the adapter card and rack per site grounding standards.

Frequently Asked Questions

Q: What is the purpose of the IC695CRH035?
A: It connects existing Series 90-70 ALG320 field wiring to RX3i ALG708 analog modules without requiring field rewiring [citation:7].

Q: How many Expander modules can be daisy-chained?
A: Up to seven Expander modules can be daisy-chained off the Base Converter module, supporting a maximum of 120 total inputs [citation:17].

Q: What CPU firmware version is required?
A: RX3i CPU firmware version 3.0 or later is required for compatibility with this harness assembly [citation:2].
