IC697ACC624

GE Fanuc IC697ACC624 Rack Cooling Fan Assembly

A kan haja (13 guda), a shirye don aikawa

  • Manufacturer: General Electric

  • Product No.: IC697ACC624

  • Product Type: Rack Fan Assembly

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 1800g

  • Shipping port: Xiamen

  • Warranty: 12 months

Dokar Mayar da Kaya na Kwanaki 30 · Garantin Watanni 12
  • Isarwa Cikin Gaggawa
  • Tallafi na awa 24 a rana, kwana 7 a mako
  • Tabbacin Inganci

Bayani

Product Overview

The GE Fanuc IC697ACC624 is a high-performance 240V cooling fan assembly designed specifically for the Series 90-70 and RX7i PLC racks. This accessory ensures optimal thermal management for densely populated racks, utilizing dual high-efficiency fans to prevent system overheating and prolong the lifespan of critical electronic components.

Engineered for industrial reliability, this assembly is remarkably easy to manage with a total weight of approximately 4 pounds (1.8 kg). It features low-noise axial fans protected by flame-retardant filter retainers, making it an essential addition for maintaining system stability in vertical or horizontal mounting orientations.

Technical Specifications

Parameter Details
Manufacturer GE Fanuc (Series 90-70)
Model Number IC697ACC624
Rated Voltage 240 Volts AC (50–60 Hz)
Airflow 108 CFM per fan (without filter)
Filter Rating Polyurethane Foam, 30 PPI
Noise Level < 40 dBA (Low-noise design)

Key Performance Features

  • Dual-Fan Redundancy: Equipped with two independent axial fans, each consuming only 16–20 Watts while providing high-volume air movement.
  • Advanced Dust Protection: Features 30 PPI polyurethane foam filters that effectively trap debris, housed in UL94V-0 flame-retardant plastic for enhanced safety.
  • Broad Rack Compatibility: Mounts directly onto 5-slot Series 90-70 racks and 9-slot RX7i racks without complex modifications.
  • Rugged Temperature Tolerance: Designed to withstand storage temperatures from -40°C to +85°C, ensuring durability in extreme warehouse or plant conditions.

Installation & Maintenance

The IC697ACC624 is designed for straightforward integration. Its versatile mounting capability allows for both vertical and horizontal placement depending on the rack airflow requirements. Regular maintenance of the polyurethane filters is recommended to maintain the peak 108 CFM airflow efficiency and ensure the low-noise signature of the assembly remains below 40 dBA.

Technical FAQs

Q1: What is the line current for each fan?
A1: Each fan operates at a line current of 0.09–0.14 Amps, ensuring low power draw for the cooling provided.

Q2: Is the filter replaceable?
A2: Yes, the 30 PPI polyurethane foam filter is designed for easy access within the UL94V-0 retainer for cleaning or replacement.

Q3: Does this model support 120V input?
A3: No, the IC697ACC624 is specifically configured for 240V AC power. For 120V requirements, please refer to the corresponding accessory model in the Series 90-70 range.

Condition: New & Original in Factory Packing

Warranty: 12 Months Factory Warranty
