330901-22-90-10-01-05

ATEX IECEx Probe | Bently Nevada 330901-22-90-10-01-05

A kan haja (26 guda), a shirye don aikawa

  • Manufacturer: Bently Nevada

  • Product No.: 330901-22-90-10-01-05

  • Product Type: 3300 NSv Probe

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 500g

  • Shipping port: Xiamen

  • Warranty: 12 months

Dokar Mayar da Kaya na Kwanaki 30 · Garantin Watanni 12
  • Isarwa Cikin Gaggawa
  • Tallafi na awa 24 a rana, kwana 7 a mako
  • Tabbacin Inganci

Bayani

Bently Nevada 330901-22-90-10-01-05 3300 NSv Proximity Probe

The Bently Nevada 330901-22-90-10-01-05 is a 3300 NSv proximity probe with 1/4-28 UNF thread. Weighing approximately 0.5 kg, it operates from -52°C to +177°C with ATEX/IECEx/NEPSI approvals for Zone 1/21 hazardous areas, delivering precise vibration monitoring with 0.5ms dynamic response.

Model Number Breakdown

330901-22-90-10-01-05

  • 330901 – Base probe model
  • 22 – 2.2 in unthreaded section
  • 90 – 9.0 in stainless steel case
  • 10 – 1.0 m cable length
  • 01 – ClickLoc connector type
  • 05 – Multi-agency approval package

Product Identification

  • Manufacturer: Bently Nevada
  • Product Number: 330901-22-90-10-01-05
  • Type: 3300 NSv Proximity Probe
  • Thread: 1/4-28 UNF
  • Total Length: 1.0 meter (39 in)
  • Approvals: ATEX, IECEx, NEPSI

Core Specifications

Parameter Value
Weight Approx. 0.5 kg
Thread 1/4-28 UNF
Max Torque 7.3 N•m (65 in•lb)
Thread Engagement Limit 0.375 in
Operating Temperature -52°C to +177°C
Thermal Shock Drift < 5% at 100°C/min
Unthreaded Length 2.2 in
Case Length 9.0 in
Total Length 1.0 m (39 in)
Cable Type 75Ω FEP-insulated
DC Resistance @1m 4.2 ± 0.5 Ω
Seal Integrity Viton O-ring, 2.5 bar @150°C (10,000 cycles)
Dynamic Response 0.5 ms rise time (10-90%) @10kHz
Positional Repeatability 0.003 mm after 50,000 cycles
Protection Rating IP67
MTBF 25,000 hours @85°C

Compliance and Durability

  • Certifications: ATEX, IECEx, NEPSI approvals for Zone 1/21 hazardous areas.
  • Material Endurance: 304 SST case resists 500hr salt spray (ASTM B117) with zero corrosion.
  • PPS Tip: Maintains <0.1% dimensional change at 120°C.
  • Service Life: 12-month warranty with 25,000hr MTBF at 85°C continuous operation.

Installation

  • Apply maximum torque of 7.3 N•m (65 in•lb) to probe thread.
  • Do not exceed 0.375 in thread engagement.
  • Ensure operating temperature stays within -52°C to +177°C.
  • Use Viton O-ring for differential pressure sealing.
  • IP67 rated for protection against dust and water immersion.

Technical FAQs

Q1: What is the weight of the probe?
A1: Approximately 0.5 kg.

Q2: What approvals does this probe carry?
A2: ATEX, IECEx, and NEPSI for Zone 1/21 hazardous areas.

Q3: What is the dynamic response time?
A3: 0.5 ms rise time (10-90%) at 10kHz vibration frequency.

Product Resources

📄 Download PDF
🏷️ Tags: 3300 NSv Probe Proximity Probe
