330101-00-66-10-02-CN Proximity Probe 1.0m Bently Nevada

Bently Nevada 330101-00-66-10-02-CN: 8mm Vibration Probe with China Approval

The Bently Nevada 330101-00-66-10-02-CN is an 8mm proximity probe made in USA. This sensor features 3/8-24 UNF threads with standard cable and ClickLoc connector.

Key Specifications

• Manufacturer: Bently Nevada, Made in U.S.A
• Part Number: 330101-00-66-10-02-CN
• Probe Diameter: 8 mm
• Thread Size: 3/8-24 UNF
• Case Length: 6.6 inches
• Cable Length: 3.3 feet (1.0 meter total)
• Connector: Miniature coaxial ClickLoc, standard cable
• Approval: CN = Country Specific (China)
• System Weight: 323 g/m (11.4 oz/ft)

Performance Data

• Sensitivity: 7.87 V/mm ±5%
• Accuracy: ±0.025 mm at 25°C
• Linear Range: 2.3 mm (from -1V to -17V)
• Recommended Gap: 1.0 mm (40 mils)
• DC Resistance: 5.3 ± 0.7 ohms at 1.0m

Construction & Durability

• Tip Material: Polyphenylene sulfide (PPS)
• Case Material: AISI 304 stainless steel
• TipLoc Technology: 40% stronger bond strength
• Connector Lock: ClickLoc coaxial, 75 lbf secure
• Pressure Seal: Viton O-ring rated 300 PSI
• Case Torque: Max 22.6 N•m, Recommended 7.5 N•m

Environmental Ratings

• Probe Tip Temp: -52°C to +218°C (-62°F to +425°F)
• Cable Temp: -51°C to +260°C (-60°F to +500°F)
• Humidity: 100% condensing, IEC 68-2-3 compliant
• Note: Sustained below -34°C may affect pressure seal

Field Wiring

• Wire Size: 0.2 to 1.5 mm² (16-24 AWG)
• With Ferrules: 0.25 to 0.75 mm² (18-23 AWG)
• Cable Type: Three-conductor shielded triad
• Max Length to Proximitor: 305 m (1000 ft)

FAQs

Q: What is the length and weight of 330101-00-66-10-02-CN?

A: The 330101-00-66-10-02-CN has 6.6" case + 3.3' cable (1.0m total) and weighs 323 g/m (11.4 oz/ft). Total weight is approximately 323 grams.

Q: What thread size does this probe use?

A: The 330101-00-66-10-02-CN uses 3/8-24 UNF threads, standard for 8mm Bently Nevada probes.

Q: Can I download the datasheet?

A: Yes, click here for the full 3300 XL 8mm datasheet (PDF).
