330191-00-40-10-05

3300 XL ETR Probe | 330191-00-40-10-05 Bently Nevada

A kan haja (17 guda), a shirye don aikawa

  • Manufacturer: Bently Nevada

  • Product No.: 330191-00-40-10-05

  • Product Type: Proximity Probe

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 323g

  • Shipping port: Xiamen

  • Warranty: 12 months

Dokar Mayar da Kaya na Kwanaki 30 · Garantin Watanni 12
  • Isarwa Cikin Gaggawa
  • Tallafi na awa 24 a rana, kwana 7 a mako
  • Tabbacin Inganci

Bayani

Bently Nevada 330191-00-40-10-05 3300 XL ETR Proximity Probe

Bently Nevada 330191-00-40-10-05 3300 XL 8 mm Extended Temperature Range (ETR) probe. 3/8-24 UNF thread, 4.0 in case length, 1.0 m total length, 7.59Ω ±0.50 resistance.

Ordering Configuration

  • Part Number: 330191-00-40-10-05
  • Thread Type: 3/8-24 UNF (max engagement 0.563 in)
  • Unthreaded Length: 00 - 0.0 in
  • Case Length: 40 - 4.0 in (102 mm)
  • Total Length: 10 - 1.0 meter (3.3 ft)
  • Connector: Miniature coaxial ClickLoc (gold-plated)
  • Approval: 05 - CSA, ATEX, IECEx
  • Warranty: 12 months

Electrical Specifications

  • DC Resistance (1.0m): 7.59Ω ±0.50
  • Voltage Range: -17.5 Vdc to -26 Vdc (12 mA max)
  • Output Resistance: 50Ω ±5%
  • Linear Range: 2.0 mm (80 mils), 0.25 to 2.3 mm
  • Incremental Scale Factor (ISF): 7.87 V/mm (200 mV/mil) ±6.5% (ETR)
  • Deviation from Best Fit (DSL): Less than ±0.038 mm (±1.5 mils)
  • Frequency Response: 0 to 10 kHz, +0, -3 dB with 305m field wiring
  • Field Wiring: 16-24 AWG, 305m max

Mechanical Specifications

  • Probe Tip Material: Polyphenylene sulfide (PPS), 8 mm diameter
  • Probe Case Material: AISI 303/304 stainless steel
  • Cable: 75Ω triaxial PFA insulation (ETR)
  • TipLoc Encapsulation: 23% thicker vs standard probes
  • CableLoc Pull Strength: 330 N (75 lbf)
  • Connector Torque: Finger tight (0.565 N•m max)
  • Case Torque (3/8-24): Max 33.9 N•m, Rec 11.2 N•m
  • First Three Threads Torque: Max 22.6 N•m, Rec 7.5 N•m
  • Weight: 323 g per meter (0.32 kg/m)

Environmental & Temperature

  • Probe Tip Range (ETR): -52°C to +218°C (-62°F to +425°F)
  • Probe Cable Range (ETR): -51°C to +260°C (-60°F to +500°F)
  • Standard Cable Range: -52°C to +177°C (-62°F to +350°F)
  • Hazardous Areas (EPL Ga): T1 @ -55°C to +232°C
  • Pressure Seal: Viton O-ring, differential pressure sealing
  • Humidity Resistance: <3% ASF change after 56 days at 93% RH
  • Minimum Bend Radius: 25.4 mm (1.0 in)

FAQ

Q: Thread and length?
A: 3/8-24 UNF thread, 4.0 in case length, 1.0 m total length, 7.59Ω resistance. CSA/ATEX/IECEx certified (Option 05).

Q: Temperature range?
A: Probe tip -52°C to +218°C, cable -51°C to +260°C. ETR rating for high-temperature applications. Hazardous area T1 rating -55°C to +232°C.

Q: Weight and pull strength?
A: 323 g/m (0.32 kg/m). CableLoc pull strength 330 N (75 lbf). Gold-plated ClickLoc connectors with finger-tight torque.

Download Datasheet
