25mm Probe Bently Nevada 330851-02-000-030-50-01-05

A kan haja (15 guda), a shirye don aikawa

  • Manufacturer: Bently Nevada

  • Product No.: 330851-02-000-030-50-01-05

  • Product Type: Proximity Probe

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 1500g

  • Shipping port: Xiamen

  • Warranty: 12 months

Dokar Mayar da Kaya na Kwanaki 30 · Garantin Watanni 12
  • Isarwa Cikin Gaggawa
  • Tallafi na awa 24 a rana, kwana 7 a mako
  • Tabbacin Inganci

Bayani

Product Overview

The Bently Nevada 330851-02-000-030-50-01-05 is a heavy-duty 3300 XL 25 mm proximity probe designed for maximum survivability in the most demanding steam turbine Differential Expansion (DE) environments. This version includes integrated stainless steel armor for superior mechanical protection.

Proudly Made in the U.S.A., this probe is a direct physical replacement for legacy 7200 series 25mm and 35mm systems. It features a compact 30mm case with an M30x2 thread, making it ideal for tight mounting locations requiring large-scale displacement measurement.

Technical Configuration

  • Model: 330851 (3300 XL 25 mm Proximity Probe)
  • Probe Case Type (-02): M30x2 Thread
  • Unthreaded Length (-000): 0 in
  • Overall Case Length (-030): 30 mm
  • Total Length (-50): 5.0 meters (16.4 feet)
  • Armor Option (-01): With Stainless Steel Armor
  • Agency Approval (-05): Multiple Approvals (ATEX, IECEx, CSA)

Technical Specifications

Feature Details
Operating Temperature -35°C to +200°C (Intermittent up to +250°C)
Tip Material Polyetheretherketone (PEEK)
Cable Material 75 Ω triaxial, PFA insulated FluidLoc cable
DC Resistance 7.5 ± 0.8 Ω (Center to Outer Conductor)
Armor Material Flexible AISI 304 Stainless Steel
Max Torque 163 N•m (120 ft•lb)

Built for Extreme Resilience

The 3300 XL 25 mm probe series is engineered to maintain accuracy in high-temperature steam environments. The PEEK tip and PFA-insulated FluidLoc cable prevent moisture and oil from wicking through the sensor, while the stainless steel armor prevents physical damage during maintenance or from high-velocity debris.

Global Compliance & Safety

The -05 approval option ensures this probe is ready for global deployment, meeting ATEX/IECEx and CSA standards for both intrinsically safe (Zone 0) and non-sparking (Zone 2) hazardous area locations. It also complies with ABS Maritime rules and RoHS directives.

Technical FAQs

Q1: Why choose the armored (-01) version?

A1: Armor provides critical protection against crushing and abrasion in the high-stress environments of power plants and industrial facilities.

Q2: Is this compatible with my 7200 series system?

A2: Yes, the 330851 is designed as a direct physical and functional upgrade for legacy 7200 25mm and 35mm systems.

Q3: How long can it withstand 250°C?

A3: It is rated for intermittent high-temperature exposure up to +250 °C (482 °F) for periods of less than 24 hours.

Shipping Weight: 1.5kg

Product Resources

📄 Download PDF
🏷️ Tags: 3300 XL 25 mm Proximity Probe Proximity Probe
