1769-L23E-QBFC1B

1769-L23E-QBFC1B Allen-Bradley Packaged Controller 16DI 16DO

A kan haja (12 guda), a shirye don aikawa

  • Manufacturer: Allen-Bradley

  • Product No.: 1769-L23E-QBFC1B

  • Product Type: Controller Module

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 660g

  • Shipping port: Xiamen

  • Warranty: 12 months

Dokar Mayar da Kaya na Kwanaki 30 · Garantin Watanni 12
  • Isarwa Cikin Gaggawa
  • Tallafi na awa 24 a rana, kwana 7 a mako
  • Tabbacin Inganci

Bayani

Product Identification

  • Brand: Allen-Bradley
  • Catalog Number: 1769-L23E-QBFC1B
  • Product Type: CompactLogix Packaged Controller
  • Series: 1769 CompactLogix
  • Power Supply: 24V DC

Embedded I/O Specifications

  • Digital Inputs: 16 x 24V DC sinking
  • Digital Outputs: 16 x 24V DC sourcing
  • Analog Inputs: 4 channels (single-ended or differential)
  • Analog Outputs: 2 channels (single-ended)
  • High-Speed Counters: 4 channels

Communication Ports

  • Ethernet Port: 1 x 10/100 Mbps (RJ45)
  • Serial Port: 1 x RS232 (DF1, ASCII)
  • Protocols: EtherNet/IP, DF1 full-duplex, ASCII
  • TCP Connections: Up to 8 simultaneous connections

System Memory & Performance

  • User Memory: 512 KB (battery-backed)
  • Battery Type: 1769-BA lithium battery (sold separately)
  • Expansion Slots: Supports up to 2 additional 1769 I/O modules
  • Tasks Supported: 4 tasks maximum

Environmental & Installation

  • Operating Temperature: 0°C to 60°C (32°F to 140°F)
  • Storage Temperature: -40°C to 85°C (-40°F to 185°F)
  • Relative Humidity: 5% to 95% non-condensing
  • Ventilation Clearance: 50 mm (2 inches) on all sides
  • Enclosure: Must be installed in protective enclosure (IP54 minimum for Zone 2)
  • Grounding: Zinc-plated DIN rail recommended for proper grounding

FAQ

How many digital I/O points does Allen-Bradley 1769-L23E-QBFC1B have?

16 digital inputs and 16 digital outputs built-in, plus 4 high-speed counters.

What is the memory size of Allen-Bradley 1769-L23E-QBFC1B?

512 KB user memory requiring 1769-BA battery for retention.

What is the weight of Allen-Bradley 1769-L23E-QBFC1B?

0.66 kg complete with embedded I/O and communication ports.
