170ADM54080

170ADM54080 Schneider Modicon Modbus I/O Module Base

A kan haja (13 guda), a shirye don aikawa

  • Manufacturer: Schneider

  • Product No.: 170ADM54080

  • Product Type: I/O Module

  • Product Origin: FR

  • Payment:T/T, Western Union

  • Weight: 240g

  • Shipping port: Xiamen

  • Warranty: 12 months

Dokar Mayar da Kaya na Kwanaki 30 · Garantin Watanni 12
  • Isarwa Cikin Gaggawa
  • Tallafi na awa 24 a rana, kwana 7 a mako
  • Tabbacin Inganci

Bayani

170ADM54080 Schneider Modicon Momentum Modbus I/O Module Base

The 170ADM54080 is a Modbus I/O module base from Schneider Electric. It belongs to the Modicon Momentum series. This unit provides 6 discrete inputs and 3 discrete outputs.

Technical Specifications

  • Part Number: 170ADM54080
  • Manufacturer: Schneider Electric
  • Product Type: Modbus I/O module base
  • Input Voltage: 120 V AC (0 to 132 V AC range)
  • Frequency Range: 47 to 63 Hz
  • Discrete Inputs: 6 (positive logic)
  • Discrete Outputs: 3 (positive logic)
  • Communication Protocol: Modbus via RS485
  • Wiring Mode: 2 or 4 wires
  • Transmission Rate: 9600 or 19200 bit/s
  • Data Format: 8-bit RTU or 7-bit ASCII
  • Number of Addresses: 0 to 247
  • Current Consumption: 125 mA at 120 V AC
  • Surge Current: 30 mA
  • Leakage Current: 1.9 mA max at 120 V AC
  • Response Time: 12.3 to 12.5 ms at 60 Hz
  • Marking: CE
  • Certifications: CSA, UL
  • Net Weight: 0.24 kg (0.53 lbs)

FAQ

  • What communication protocol does this module use?
    The 170ADM54080 uses Modbus protocol via RS485 port with 9600 or 19200 bit/s transmission rates.
  • How many inputs and outputs does it have?
    It provides 6 discrete inputs and 3 discrete outputs with positive logic.
  • What is the module weight?
    The unit weighs 0.24 kg (0.53 lbs).
