330101-00-12-10-01-00

330101-00-12-10-01-00 Bently Nevada 8mm Probe

Faqat 8 dona qoldi

  • Manufacturer: Bently Nevada

  • Product No.: 330101-00-12-10-01-00

  • Product Type: Proximity Probe

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 323g

  • Shipping port: Xiamen

  • Warranty: 12 months

30 kunlik qaytarish siyosati · 12 oylik kafolat
  • Tez yetkazib berish
  • 24/7 Qo'llab-quvvatlash
  • Sifat nazorati

Tavsif

Product Overview

The Bently Nevada 330101-00-12-10-01-00 is an industrial-grade 3300 XL 8 mm proximity probe engineered for critical rotating machinery protection. This non-contact sensor accurately tracks radial vibration, axial thrust, and speed on high-speed assets like steam turbines and centrifugal compressors. Built with a 1.2-inch unarmored case, a patented TipLoc PPS plastic tip, and an integrated connector protector, it delivers high performance under severe thermal, chemical, and physical stress.

Core Technical Advantages

  • Connector Protection: Code 01 configuration includes a built-in connector protector over the miniature coaxial ClickLoc interface to seal out environmental contaminants.
  • High-Retention Cabling: Utilizes a patented CableLoc anchoring design that provides a powerful 330 N (75 lbf) pull strength to prevent physical cable tearing.
  • Ruggedized Sensor Tip: Thick encapsulation of the internal coil within molded PPS plastic ensures maximum physical robustness against operational abuse.

Technical Specifications

Parameter Specification Details
Brand / Model Part No. Bently Nevada / 330101-00-12-10-01-00
Thread Profile 3/8-24 UNF thread, without armor
Case Dimensions Unthreaded Length: 0.0 in / Overall Case Length: 1.2 in
Cable & Connector 1.0 meter (3.3 feet) / Miniature coaxial ClickLoc with connector protector
Linear Range 2 mm (80 mils), from 0.25 mm to 2.3 mm (10 to 90 mils / –1 to –17 Vdc)
Recommended Gap Setting -9 Vdc [approximately 1.27 mm (50 mils)] for radial vibration
Incremental Scale Factor 7.87 V/mm (200 mV/mil) ±5% (Standard 1m/5m system)
Linearity Deviation (DSL) Less than ±0.025 mm (±1 mil) within 0°C to +45°C range
DC Resistance (RPROBE) 7.59 Ω ±0.50 Ω (Center conductor to outer conductor)
Temperature Limits Operating & Storage: -52°C to +177°C (-62°F to +350°F)
Materials & Weight Polyphenylene sulfide (PPS) tip, AISI 303/304 Stainless Steel / 323 g/m

Installation & Engineering Guide

  • Voltmeter Gapping: Set the mechanical mounting position to roughly 1.27 mm (50 mils) from the target, verifying a -9 Vdc reading on your voltmeter.
  • Field Wiring Limits: Connect using 0.2 to 1.5 mm² (16 to 24 AWG) 3-conductor shielded triad cable. Maintain a maximum distance of 305 meters (1,000 feet) to the Proximitor Sensor to avoid high-frequency signal roll-off.
  • Environmental Safeguards: Do not expose the assembly to temperatures below –34°C (-30°F) to protect the internal Viton O-ring pressure seal. The scale factor remains highly stable (under 3% variance) through 56 days of 93% relative humidity.

Technical FAQs

Q1: What dimensions do the codes "00-12" represent?
A1: Code 00 indicates 0.0 inches of unthreaded length, and code 12 indicates a compact 1.2-inch fully threaded overall case length.

Q2: What extension cable capacitance is required for this 1.0-meter probe?
A2: It must pair with a 3300 XL extension cable featuring a typical capacitance of 69.9 pF/m (21.3 pF/ft) to preserve the 200 mV/mil scale calibration.

Q3: What benefit does the connector protector option provide?
A3: The code 01 connector protector physically isolates the ClickLoc connection from oil, moisture, and dust, preventing signal shorting or oxidation in exposed machine environments.
