22B-E3P0C104

22B-E3P0C104 PowerFlex 40 Drive RS-485 16kHz PWM Allen-Bradley

Omborda (19 dona), jo'natishga tayyor

  • Manufacturer: Allen-Bradley

  • Product No.: 22B-E3P0C104

  • Product Type: AC Drive

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 6500g

  • Shipping port: Xiamen

  • Warranty: 12 months

30 kunlik qaytarish siyosati · 12 oylik kafolat
  • Tez yetkazib berish
  • 24/7 Qo'llab-quvvatlash
  • Sifat nazorati

Tavsif

Allen-Bradley 22B-E3P0C104 PowerFlex 40 AC Drive

Product Overview

The Allen-Bradley 22B-E3P0C104 PowerFlex 40 Series AC drive delivers 2 HP (1.5 kW) output with 3.0 A current capacity. Operating on 600 VAC 3-phase input, this B Frame drive features sensorless vector and V/Hz control with Autotune. The IP66/NEMA 4X enclosure provides dust-tight and water-resistant protection. Weight is 6.5 kg.

Specifications

Parameter Value
Brand Allen-Bradley / Rockwell Automation
Model 22B-E3P0C104
Series PowerFlex 40
Drive Type Adjustable Frequency AC Drive
Input Voltage 600 VAC, 3-Phase, 50/60 Hz
Output Power 2 HP (1.5 kW)
Output Current 3.0 A
Enclosure Type IP66 / NEMA 4X (Dust-tight, Water-resistant)
Frame Size B Frame
Control Mode Sensorless Vector, V/Hz, Autotune
Operating Temperature -10 °C to +40 °C (Zero Stacking to 50 °C)
Display 4-digit LED + 10 status indicators + Keypad
Communication Built-in RS-485 + Optional (DeviceNet, ControlNet, EtherNet/IP, PROFIBUS DP, LonWorks, DSI Wireless)
Integrated Functions PID, Timer, Counter, Basic Logic, StepLogic
Braking Integral brake transistor
PWM Frequency Adjustable up to 16 kHz
Protection Removable MOV, Overload, Relay Pre-Charge Circuit
Mounting DIN Rail or Panel Mount
Weight 6.5 kg

Key Features

  • 600 VAC 3-phase input for high-voltage applications
  • Sensorless vector and V/Hz control with Autotune
  • IP66 / NEMA 4X dust-tight and water-resistant enclosure
  • Built-in RS-485 with optional fieldbus modules
  • Integrated PID, Timer, Counter, Logic, and StepLogic functions
  • Integral brake transistor for dynamic braking
  • Adjustable PWM frequency up to 16 kHz
  • Removable MOV, overload, and relay pre-charge protection
  • DIN rail or panel mounting flexibility

Installation Notes

Mount the drive on DIN rail or panel using the B Frame mounting provisions. Ensure adequate clearance for airflow. The IP66/NEMA 4X enclosure allows installation in washdown or dusty environments. Set motor parameters using the integral keypad or RS-485 communication.

FAQs

Q1: What is the maximum ambient temperature for zero stacking?

A1: Zero stacking is supported up to 50 °C. For operation above 40 °C, derating may apply.

Q2: Can this drive be used with single-phase input?

A2: No. The 22B-E3P0C104 requires 3-phase 600 VAC input for proper operation.

Q3: What communication options are available?

A3: Built-in RS-485 is standard. Optional modules support DeviceNet, ControlNet, EtherNet/IP, PROFIBUS DP, LonWorks, and DSI Wireless.
