Bently Nevada 330104-00-16-05-02-CN | Case Probe

Product Overview

The Bently Nevada 330104-00-16-05-02-CN is a high-precision 3300 XL 8 mm proximity probe designed for critical machinery protection and vibration monitoring. This model features an M10 x 1 metric thread and integrated stainless steel armor, providing superior physical protection for the cable in demanding industrial environments.

Engineered with a polyphenylene sulfide (PPS) tip and an AISI 303/304 stainless steel case, this probe ensures long-term stability and resistance to process fluids. The assembly, which has a typical weight of 0.323 kg, utilizes a miniature coaxial ClickLoc™ connector and a Viton® O-ring seal to maintain differential pressure integrity between the tip and the case.

Technical Configuration

Key Performance Features

• Robust Armored Design: The 330104 series includes a stainless steel armor sleeve that prevents cable damage from abrasion or kinking during installation.
• Precision Signal Transmission: Features a nominal DC resistance of 7.45 ± 0.50 Ω, ensuring high-fidelity data transfer to the Proximitor® Sensor.
• Environmental Resilience: The PPS tip and Viton® O-ring seal provide excellent chemical resistance and thermal stability for harsh process compressor applications.
• Industry Standard Compliance: Fully compliant with API 670 standards for non-contacting vibration monitoring on shaft diameters.

Installation & Calibration

The 330104-00-16-05-02-CN is calibrated for an AISI 4140 steel target with a standard gap of 1.27 mm (50 mils). It is designed to be used as part of a complete 3300 XL 8 mm system, including a Proximitor® Sensor and an extension cable. Performance is optimized for operation with a -24 Vdc power supply, providing an output resistance of 50 Ω.

Technical FAQs

Q1: What is the benefit of the ClickLoc™ connector?
A1: The ClickLoc™ system provides a self-locking, vibration-proof connection that ensures signal integrity even in high-frequency machinery environments.

Q2: Can this probe be used in high-pressure applications?
A2: Yes, the Viton® O-ring design is specifically engineered to seal differential pressure between the probe tip and the stainless steel case.

Q3: Does the armor affect the probe's flexibility?
A3: The armor provides protection while maintaining a reasonable bend radius, allowing the cable to be routed through standard conduit systems without compromising the internal triaxial cable.

Condition: New & Original in Factory Packing

Warranty: 12 Months Factory Warranty
