330104-00-04-10-02-00 Bently Nevada 3300 XL Armor Probe

Product Overview

The Bently Nevada 330104-00-04-10-02-00 is an advanced 3300 XL 8 mm Proximity Probe designed for critical industrial monitoring. This model features integrated armor for superior cable protection and an M10 x 1 metric thread. Manufactured in the U.S.A., it provides highly accurate displacement and vibration data by measuring the gap between the probe tip and a conductive target. Its robust design ensures stability and precision even in environments with significant pressure differentials and temperature fluctuations.

Core Technical Advantages

Enhanced Mechanical Armor

Unlike standard probes, this configuration includes a 1.0-meter armored cable. This added layer of protection prevents physical damage from abrasion, crushing, or sharp bends, ensuring signal integrity in the most demanding machinery environments.

High-Pressure Sealing

The probe tip is constructed from Polyphenylene Sulfide (PPS) and utilizes a Viton® O-ring to seal differential pressure between the tip and the AISI 303/304 stainless steel case. This design maintains measurement accuracy while preventing fluid or gas leakage from the machine housing.

Industry-Standard Precision

The 3300 XL system is calibrated for AISI 4140 steel targets at a 1.27 mm (50 mils) gap. With a supply sensitivity of less than 2 mV variation per volt change, it delivers extremely stable output signals to the Proximitor® sensor.

Technical Specifications

Engineering Installation Notes

• Target Calibration: This system is strictly calibrated for AISI 4140 steel. Accuracy specifications do not apply to other target materials without custom recalibration.
• Armored Cable Handling: While the armor protects the inner core, ensure the minimum bend radius is maintained to prevent stress on the internal coaxial structure.
• Altitude & Temperature: Optimal performance is achieved between +18°C and +27°C at altitudes below 2000 meters.

Technical FAQs

Q1: What is the benefit of the ClickLoc connector?

A1: The ClickLoc system ensures a secure, vibration-proof connection with a audible click, preventing signal loss or high resistance common in standard threaded connectors.

Q2: Does this probe include agency approvals?

A2: The "00" option for agency approval indicates "Not Required." This version is typically used in non-hazardous areas or where local certification is not mandatory.

Q3: How does the 40mm case length affect installation?

A3: The 40mm overall case length determines the depth the probe can reach into a machine housing. Ensure your mounting bracket or port aligns with this fixed mechanical dimension.
