Allen-Bradley 1762-OB16: 16-Channel 24VDC Output Module

The Allen-Bradley 1762-OB16 is a 16-channel 24VDC output module for MicroLogix systems. This compact module provides fast switching with 0.1ms on delay and 1.0ms off delay.

Core Specifications

  • Part Number: 1762-OB16
  • Brand: Allen-Bradley
  • Output Voltage Range: 20.4 to 26.4 VDC
  • Voltage Category: 24 VDC
  • Number of Outputs: 16
  • Output Groups: 1 group (Outputs 0 to 15)

Performance Metrics

  • Signal Delay On: 0.1 ms
  • Signal Delay Off: 1.0 ms
  • Max Output Current: 0.5 A per channel
  • Max Load Current: 8 A per group

Installation Data

  • Compatible Controllers: MicroLogix 1100, 1200, 1400
  • Max Modules Supported: 4 with MicroLogix 1100
  • Max Modules Supported: 6 with MicroLogix 1200
  • Max Modules Supported: 7 with MicroLogix 1400
  • Weight: 235 g (0.52 lbs)

Environmental Ratings

  • Operating Temperature: 0°C to 60°C (32°F to 140°F)
  • IP Rating: IP20
  • Mounting: DIN rail or panel mount

Package Contents

  • 1x Allen-Bradley 1762-OB16 output module
  • Factory sealed anti-static packaging
  • Original Rockwell Automation box

Shipping Information

  • DHL, FedEx, or UPS Express worldwide
  • Same-day dispatch for in-stock items
  • Tracking provided immediately

FAQs

Q: What is the weight of 1762-OB16?

A: The Allen-Bradley 1762-OB16 weighs 235 g (0.52 lbs).

Q: Which controllers work with 1762-OB16?

A: The Allen-Bradley 1762-OB16 works with MicroLogix 1100, 1200, and 1400 controllers.

Q: What is the output current per channel?

A: The Allen-Bradley 1762-OB16 provides 0.5 A per channel with 8 A per group maximum.
