Schneider 140DDO35310C 32 Output Sink Module Quantum

Overview

The Schneider Electric 140DDO35310C is a discrete output module for Modicon Quantum systems. It provides 32 sink outputs with 24V DC negative logic. This module ensures reliable control for industrial automation tasks.

Key Specifications

• Manufacturer: Schneider Electric – Modicon Quantum series
• Model: 140DDO35310C – Discrete output module
• Channels: 32 outputs, negative logic (sink)
• Output Voltage: 24V DC (19.2-30V range)
• Surge Current: 5A per point
• Max Leakage: 0.4 mA at 24V

Output Groups

• 32 channels split into 4 groups of 8 outputs.
• Each group handles up to 4A total load current.
• Voltage drop below 0.4V at 0.5A per channel.
• Requires 2 output words for addressing.

Performance

• Power dissipation: 2.0W + (0.4V × total load current).
• Bus current requirement: 330 mA.
• Withstands 50V for 1 second decaying pulse.
• Standard format fits Quantum backplanes.

Environmental Durability

• Conformal coating (Humiseal 1A33) for harsh environments.
• Operating temperature: 0-60°C.
• Certifications: UL 508, CSA, CE marked.
• Net weight: 0.45 kg.

Package & Shipping

• Dimensions: 16.3 × 4.5 × 31.2 cm, net weight 0.45 kg.
• Includes: One 140DDO35310C module with documentation.
• Shipping: Fast delivery via FedEx, UPS, or DHL.

FAQ

Q: What is negative logic sink output?

A: The module connects the load to ground. Current sinks from load to output when activated.

Q: How does 140DDO35310C differ from 140DDO35301C?

A: This model uses sink logic. The 140DDO35301C uses source logic. Choose based on your wiring preference.

Q: What is the maximum load per channel?

A: Each channel handles 0.5A continuous. Surge rating is 5A for transient loads.
