IC693CBK001 GE Fanuc High-Density 3m PLC Wiring Cables

GE Fanuc IC693CBK001 Cable Kit

The GE Fanuc IC693CBK001 is a high-density, pre-wired cable kit designed for connecting Series 90-30 high-density PLC I/O modules to external terminal blocks. Featuring two heavy-duty, 3-meter right-angle cables, this kit ensures stable electrical connections and clean routing within industrial enclosures.

Key Advantages

• Dual-Cable Match: Includes both IC693CBL327 and IC693CBL328 cables for complete high-density module wiring.
• Space-Saving Profile: Molded right-angle headers allow tight bend radius execution in dense electrical cabinets.
• Heavy-Duty Conductors: Industrial-grade 22 AWG solid copper wire supports stable signal integrity across longer runs.

Technical Specifications

Quick Installation

• Module Interface: Align the 24-pin Fujitsu female connector to the male faceplate pins on the high-density module.
• Cable Direction: Orient the right-angle cable exit downward to reduce strain on the faceplate assembly.
• Terminal Block Link: Route the opposite end of the 3-meter harness directly to your remote DIN-rail terminal panel.

Technical FAQs

Q1: What specific modules require this cable combination?
A1: This kit provides connectivity for 32-point high-density discrete modules (such as IC693MDL655 and similar cards) requiring dual Fujitsu port links.

Q2: Can individual conductors handle full PLC group currents?
A2: Each conductor is rated for 1.2 Amps maximum. Total current summing across the card must respect individual module group tolerances.

Q3: Is this kit suitable for deployment in high-temperature settings?
A3: Yes, the heavy-duty composition and UL 94V-0 rated insulation run safely across an industrial operating span from -20°C to +60°C.
