Discrete Output 170ADO35000 Schneider Electric 24V DC

Product Identification

• Manufacturer: Schneider Electric
• Part Number: 170ADO35000
• Product Line: Modicon Momentum
• Product Type: Discrete Output Module
• UPC: 785901308003

Physical Specifications

• Weight: 0.26 kg (0.56 lbs)
• Operating Temperature: 0 to 60°C
• Storage Temperature: -40 to 85°C
• Installation Location: Pollution Degree 2

Output Specifications

• Outputs: 32 solid-state outputs
• Output Voltage Range: 0-24 V DC rated
• Surge Current: 5 A for 1 ms duration
• Voltage Drop: <0.5 V at 0.5 A
• Max Output Frequency: 1 kHz

Protection & Immunity

• Overload Protection: Electronically protected
• Insulation Voltage: 4 kV per IEC 801-2
• Air Discharge Voltage: 8 kV per IEC 801-2
• Radiated Immunity: 10 V/m, 80-1000 MHz

Compliance & Certifications

• CSA Approved
• UL Approved
• CE Compliant
• RoHS Compliant
• IEC 801-2 compliant

Key Features

• 32 high-density outputs in compact form factor
• 5 A surge capability for demanding loads
• 4 kV insulation for enhanced safety
• 8 kV air discharge protection
• 10 V/m radiated immunity for noisy environments
• Global certifications for worldwide use

Compatibility

• For Modicon Momentum automation platforms
• Works with Momentum bases and adapters
• Genuine Schneider Electric part

FAQ

How many outputs does 170ADO35000 have?

32 solid-state outputs with 0-24 V DC rated voltage range.

What protection features are included?

Electronic overload protection, 4 kV insulation, and 8 kV air discharge protection.

What certifications does this module hold?

CSA, UL, CE, and RoHS compliant with IEC 801-2 standards.
