Bently Nevada 3500/94M-07-12-00 Display Unit

Bently Nevada 3500/94M-07-12-00 VGA Display Module with Router Box

The Bently Nevada 3500/94M-07-12-00 is a VGA display module configured with a Display Router Box. This version includes no physical display, allowing you to connect remote monitors via the included 20 ft (6m) cable.

Technical Specifications

• Brand & Model: Bently Nevada 3500/94M-07-12-00
• Configuration: Router box, no display included
• Cable: 20 ft (6m) Display Router Box cable
• Operating Temp: -20°C to 65°C
• Storage Temp: -40°C to 85°C
• Humidity: 95% non-condensing
• Power Consumption: 4.6 watts max (module)
• Module Dimensions: 241.3 mm x 24.4 mm x 241.8 mm
• Module Weight: 0.73 kg

Display Router Box Specifications

• Power Input: +24 Vdc ± 6% (22.5 to 25.5 Vdc range)
• Power Consumption: 4.7 watts max
• Inputs: VGA video, RS232 touch data
• Outputs: VGA video, RS232 touch data
• Status LED: OK indicator for proper operation

System Requirements

• Required Module: 3500/22 Transient Data Interface (TDI)
• Firmware: 3500/94M 4.06 Rev C, TDI Rev 1.71 or newer
• Rack Space: 1 front slot + 1 rear slot
• Software: Rack Config 5.6+, Op Display 2.21+, Data Acq 1.22+

Package Contents

• 1 x 3500/94M-07-12-00 Monitor Module
• 1 x I/O Module
• 1 x Display Router Box
• 1 x 20 ft (6m) Router Box Cable
• Display not included (configured for remote monitor use)

Shipping

• Total Weight: 1.07 kg (module package only)
• Packaging: Anti-static protection
• Carriers: FedEx, UPS, DHL

FAQs

• What is the 3500/94M-07-12-00 used for?
  This configuration connects remote displays to your 3500 rack. The router box sends video and touch signals up to 20 ft away.
• Does this include a display?
  No. The -07 configuration means router box only. You supply your own VGA-compatible monitor.
• What cable is included?
  The -12 option includes a 20 ft (6m) Display Router Box cable for connecting the router box to a remote display.
