Bently Nevada 330103-00-05-05-02-00 Vibration Transducer Probe

Product Overview

The Bently Nevada 330103-00-05-05-02-00 is a high-precision 3300 XL 8 mm Proximity Probe engineered for critical machinery vibration monitoring and rotor position measurements. Tailored for heavy-duty industrial rotating equipment including turbines, compressors, and pumps, this M10x1 metric threaded eddy current transducer ensures continuous signal stability across extreme temperature ranges from -52°C to +177°C (-62°F to +350°F). Built with a Polyphenylene Sulfide (PPS) probe tip and AISI 303/304 stainless steel casing, it incorporates a 0.5-meter cable terminating in an IP67-rated Miniature Coaxial ClickLoc® connector with Viton® O-ring sealing. The module features a net weight of 0.32 kg (0.71 lbs) for reliable, long-term deployment in hazardous locations.

Key Advantages

• High Thermal Stability PPS Tip: Resistant to chemical degradation from oils and acids, providing operation up to 260°C.
• Robust Stainless Steel Construction: AISI 303/304 stainless steel body delivers corrosion resistance in demanding field environments.
• ClickLoc® Coaxial Connector: IP67-rated connector ensures environmental sealing against dust ingress and fluid immersion.
• Viton® O-Ring Pressure Sealing: Rated for up to 10 bar differential pressure to safeguard internal mechanical assemblies.
• Hazardous Location Certified: Approved for ATEX/IECEx Zone 0 and Class I Div 1 intrinsically safe installations.

Technical Specifications

Frequently Asked Questions

Q1: What are the cable length and connector types for this probe?

A1: It includes a 0.5-meter cable with an IP67 Miniature Coaxial ClickLoc® connector.

Q2: What thread pattern does the 330103 probe use?

A2: Features an M10x1 metric thread with 00 mm unthreaded and 50 mm total case length.

Q3: How much does the Bently Nevada 330103 probe weigh?

A3: The estimated net weight is 0.32 kg (0.71 lbs).
