Bently Nevada 330101-00-18-10-02-CN 3300 XL Probe

Product Overview

The Bently Nevada 330101-00-18-10-02-CN is a 3300 XL 8 mm proximity probe designed for precision vibration and position monitoring of rotating machinery. It features a 3/8‑24 UNF thread (without armor), 1.8 inch overall case length, and 1.0 metre total length. Equipped with a miniature coaxial ClickLoc connector and standard cable. Weight: 0.323 kg.

Core Advantages

Country‑Specific Approvals

CN suffix indicates country‑specific agency approvals, ensuring regional regulatory compliance.

Compact 1.8 Inch Case

Shorter case length (1.8 in) provides installation flexibility in tight machinery spaces.

ClickLoc Connector

Miniature coaxial ClickLoc ensures secure, reliable connections with quick mating and unmating.

Specifications

Installation Tips

Mounting

Use 3/8‑24 UNF thread. Recommended installation torque: 15.2 N•m (133 in•lb) for secure mounting.

Gap Setting

For radial vibration monitoring, set probe gap to approximately -9 Vdc (1.27 mm / 50 mils).

Cable Routing

Avoid sharp bends near the ClickLoc connector. Maintain minimum bend radius of 25.4 mm (1.0 in).

Why Choose 330101-00-18-10-02-CN?

Bently Nevada 3300 XL reliability in a compact 1.8 inch case. PPS tip with AISI 303/304 SST body. ClickLoc connector for secure connections. CN country‑specific approvals for regional compliance. 8mm design offers thicker encapsulation for enhanced durability.

FAQs

Q1: What does the CN suffix mean?
A1: CN indicates country‑specific agency approvals for regional regulatory compliance.

Q2: What is the overall case length?
A2: 1.8 inches.

Q3: What is the operating temperature range?
A3: -51°C to +177°C.
