4 Channel 170AAO12000 Schneider Modicon Momentum Output Module

Product Identification

• Manufacturer: Schneider Electric
• Part Number: 170AAO12000
• Product Line: Modicon Momentum
• Product Type: Analog Output Module
• EAN: 3595861147713

Physical Specifications

• Weight: 0.215 kg (0.474 lbs)
• Power Supply: 24 VDC
• Current Consumption: 150 mA (actuator), 530 mA (base)
• Max Power Dissipation: 8.5 W
• Local Signaling: 4 LEDs for channel status

Output Specifications

• Number of Outputs: 4 analog outputs
• Output Type: Analog
• Current Signal: 0 to 20 mA
• Voltage Signal: -10V to 10V
• Data Format: 16-bit
• Update Time: 2 ms
• Max Load Capacitance: 1 µF

Resolution Details

• Voltage Signal Resolution: 12 bits + sign (for ≥ 1 Kohm load)
• Current Signal Resolution: 12 bits + sign (for ≤ 0.6 Kohm load)

Key Features

• Four versatile analog outputs with current and voltage options
• Dual signal types: 0-20 mA current and -10V to 10V voltage
• 16-bit data format for precise control
• Fast 2 ms update time for responsive applications
• 4 LED indicators for clear channel status monitoring
• Compact lightweight design at only 0.215 kg
• 24 VDC power supply with low current consumption
• Genuine Schneider Electric Modicon Momentum series

Compatibility

• For Modicon Momentum automation platforms
• Works with Momentum bases and adapters
• Suitable for precision analog control applications

FAQ

How many outputs does 170AAO12000 have?

Four analog outputs supporting both current and voltage signals.

What signal types are supported?

0 to 20 mA current and -10V to 10V voltage signals.

What is the update time for this module?

Fast 2 ms update time for real-time control applications.
