330903-00-04-05-01-00 Bently Nevada | M8x1 Probe

330903-00-04-05-01-00 Bently Nevada | 3300 NSv M8x1 Probe 40mm Case with Protector

The 330903-00-04-05-01-00 is a proximity probe from Bently Nevada 3300 NSv series with M8x1 thread and connector protector. 0.5m length, 40mm case. New factory sealed. Weight: 150g (5.3 oz) max. 12-month warranty.

▸ Configuration

• Model: 330903 - M8x1 thread, without armor
• Unthreaded length: 0 mm
• Case length: 40 mm
• Total cable: 0.5 meter (20 in)
• Connector: Miniature coaxial ClickLoc with connector protector, standard cable
• Approvals: Not required (-00)

▸ Key Specifications

• Linear range: 1.5 mm (60 mils) from 0.25-1.75 mm
• Scale factor: 7.87 V/mm (200 mV/mil) ±12.5%/-20%
• Deviation: Less than ±0.06 mm (±2.3 mils)
• Frequency response: 0-10 kHz, +0/-3 dB
• Probe DC resistance: 4.0 ±0.5 Ω (0.5m)
• Recommended gap: 1.0 mm (40 mils)

▸ Electrical & Mechanical

• Tip material: PPS
• Case material: AISI 304 SST
• Cable: 75Ω coaxial, FEP insulated, standard
• Min bend radius: 25.4 mm
• Max torque: 0.56 N•m (finger tight)
• Case torque max/rec (M8x1): 7.3 / 5.1 N•m
• Max thread engagement (M8x1): 12 mm
• Weight: 150g (5.3 oz) max

▸ Temperature & Environment

• Operating/Storage: -52°C to +177°C
• Pressure seal: Viton O-ring
• Field wiring max: 305 m (1000 ft) to monitor
• Wire gauge: 16-24 AWG (18-23 AWG with ferrules)
• Target min/recommended: 8.9 mm / 13 mm diameter

▸ Features

• M8x1 thread for compact installations
• 40mm ultra-short case length
• ClickLoc connector with protective boot
• Standard 75Ω coaxial FEP cable
• Interchangeable with 3300 RAM probes
• Increased chemical resistance for compressors
• 0.5m cable length

▸ Shipping

• FedEx, UPS, DHL worldwide

▸ FAQ

1. What thread size?
M8x1 thread for smaller mounting applications.

2. What is the connector protector?
Protective boot shields ClickLoc connector during installation.

3. Temperature range?
-52°C to +177°C operating and storage.
