SKU:22B-V2P3N104
Allen-Bradley 22B-V2P3N104 120V 1-Phase 0.5HP Inverter
Manufacturer: Allen-Bradley
Product No.: 22B-V2P3N104
Product Type: AC Drive
Product Origin: USA
Payment:T/T, Western Union
Weight: 2190g
Shipping port: Xiamen
Warranty: 12 months
Paylaşmaq
- Sürətli Çatdırılma
- 24/7 Dəstək
- Keyfiyyət təminatı
Təsvir
Allen-Bradley 22B-V2P3N104 PowerFlex 40 0.5 HP AC Drive
The Allen-Bradley 22B-V2P3N104 is a PowerFlex 40 adjustable frequency AC drive engineered for compact variable speed control of low-power three-phase induction motors. Operating on a single-phase 100–120V AC input, it delivers 2.3 A output current and 0.5 HP (0.4 kW) power output. It features Sensorless Vector Control for high low-speed torque, an IP20 NEMA/UL Open panel-mount enclosure, and integrated RS-485 communications. Weighing 2.19 kg with dimensions of 260 mm x 130 mm x 180 mm, this unit offers standard non-filtered drive capabilities with an intuitive front operator keypad.
Technical Specifications
| Brand / Manufacturer | Allen-Bradley / Rockwell Automation |
| Complete Catalog Number | 22B-V2P3N104 |
| Product Line & Control Mode | PowerFlex 40 Series | Sensorless Vector Control (SVC) & V/Hz |
| Input Voltage & Phase | 100–120V AC | 1-Phase Input |
| Output Rating & Power | 2.3 Amps Output | 0.5 HP (0.4 kW) Three-Phase Output |
| Enclosure Rating & Filter Option | IP20, NEMA/UL Type Open | No CE-Compliant Filter |
| Mounting Type & Interface | Panel Mount | Integrated Digital Keypad Display |
| Communication Protocols | Built-in RS-485 (Modbus RTU / DSI Serial) |
| Dimensions & Net Weight | 260 mm × 130 mm × 180 mm (10.2 × 5.1 × 7.1 in) | Net Weight: 2.19 kg |
Quick Installation Guide
- Mount drive vertically on flat panel allowing adequate spacing for airflow around IP20 housing.
- Connect 100–120V AC single-phase power supply line to inputs R/L1 and S/L2 with proper grounding.
- Connect 3-phase motor leads to outputs U/T1, V/T2, W/T3 and set drive motor parameters via front keypad.
Technical FAQs
Q1: What input voltage supply is required for the 22B-V2P3N104 drive?
A1: It operates on a single-phase 100–120V AC line input and converts it to control a standard 3-phase AC induction motor.
Q2: Does the 22B-V2P3N104 come with an EMC filter?
A2: No, catalog number 22B-V2P3N104 represents a standard frame without a built-in CE-compliant filter.
Q3: What are the physical weight and dimensions of this drive?
A3: It measures 260 mm x 130 mm x 180 mm (10.2 x 5.1 x 7.1 inches) and has a net weight of 2.19 kg.
Əlavə Texniki Xüsusiyyətlər
Skalyar (V/f)
Vektor
AC ilə işləyən
Alış Rəhbəri
- Sifariş verməzdən əvvəl dəqiq model, hissə nömrəsi və spesifikasiyaları təsdiqləyin.
- Mövcud maşın və ya idarəetmə sistemlərinizlə uyğunluğu təmin edin.
- Texniki dəstək üçün sale@etowonauto.com ünvanına və ya +8617859788089 nömrəsinə müraciət edin.
- Çatdırılma variantlarını, çatdırılma müddətlərini və göndərmə tələblərini nəzərdən keçirin.
- Quraşdırma zamanı istehsalçı təlimatlarına və ən yaxşı təcrübələrə əməl edin.
Göndərmə və Qaytarma
Anbarda olan məhsullar adətən eyni iş günü göndərilir. Hal-hazırda stokda olmayan məhsullar üçün göndərmə vaxtları mövcudluğa görə dəyişə bilər. Beynəlxalq çatdırılma mövcuddur və çatdırılma xərcləri təyinat, çəki və daşıyıcı seçiminə əsasən hesablanır.
Qaytarma məhsulun qəbulundan etibarən 30 gün ərzində qəbul edilir, məhsullar istifadə olunmamış və orijinal vəziyyətdə olduqda. Qaytarma göndərmə xərcləri müştərinin üzərinə düşür. Hər hansı məhsulu qaytarmazdan əvvəl qaytarma icazəsi almaq üçün bizimlə əlaqə saxlayın.
Ətraflı məlumat üçün zəhmət olmasa Çatdırılma və Qaytarma Siyasətimizi nəzərdən keçirin.
