1769-L27ERM-QBFC1B 1MB Memory Dual Ethernet Allen-Bradley

Allen-Bradley 1769-L27ERM-QBFC1B: CompactLogix Motion Controller

The Allen-Bradley 1769-L27ERM-QBFC1B is a CompactLogix controller with integrated motion control and embedded I/O. This powerful PLC supports 16 axes over Ethernet and features 1MB user memory with 1GB SD card. Engineers choose the 1769-L27ERM-QBFC1B for small machine control requiring high-speed motion and flexible communication.

Core Specifications

• Part Number: 1769-L27ERM-QBFC1B
• Memory: 1MB user + 1GB SD card
• I/O Capacity: 4 local modules + 1 expansion bank
• Communication: Dual EtherNet/IP + USB
• Motion Control: 16 axes over Ethernet
• Processor: 32-bit RISC
• Ethernet Ports: 2 (10/100 Mbps)
• Programming Languages: Ladder, ST, FBD, SFC
• Weight: 1.36 kg (3.0 lbs)
• Operating Temperature: 0°C to 60°C (32°F to 140°F)

Embedded I/O

• 16 x 24VDC digital inputs (sinking/sourcing)
• 16 x 24VDC sourcing digital outputs
• 4 x universal analog inputs (TC/RTD/voltage/current)
• 2 x analog outputs (voltage/current configurable)
• 4 x high-speed counter inputs

System Compatibility

• Studio 5000 programming environment
• 1769 Compact I/O modules
• PanelView HMI terminals
• Kinetix servo drives
• PowerFlex drives

Package Contents

• 1x Allen-Bradley 1769-L27ERM-QBFC1B controller
• 1x 1GB SD memory card
• 1x Terminal block
• Mounting hardware and documentation
• Factory sealed anti-static packaging

Shipping Information

• FedEx, UPS, DHL Express worldwide
• Same-day dispatch for in-stock items
• Tracking provided immediately

FAQs

Q: Weight of Allen-Bradley 1769-L27ERM-QBFC1B?

A: 1.36 kg (3.0 lbs).

Q: How many motion axes does it support?

A: 16 axes over EtherNet/IP.

Q: What memory card is included?

A: 1GB SD card pre-installed.

Download Detailed Product Specifications PDF
