SKU:1762-L24BWA
1762-L24BWA Allen-Bradley MicroLogix 1200 Controller
Manufacturer: Allen-Bradley
Product No.: 1762-L24BWA
Product Type: Controller Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 900g
Shipping port: Xiamen
Warranty: 12 months
Paylaş
- Hızlı Teslimat
- 7/24 Destek
- Kalite Güvencesi
Açıklama
Allen-Bradley 1762-L24BWA MicroLogix 1200 PLC
Allen-Bradley 1762-L24BWA | MicroLogix 1200 Programmable Logic Controller with 14 DC inputs and 10 relay outputs. Compact all-in-one design integrates power supply, I/O, communication ports, and memory in a single enclosure. Supports DIN rail or panel mounting. Weight: 0.9 kg (2 pounds).
Key Features
14 digital inputs (24VDC sink/source, including 4 fast inputs). 10 relay outputs. Integrated RS-232 port (8-pin mini-DIN). Supports DH-485, DF1 Full/Half-duplex, DF1 Radio Modem, Modbus Master/Slave, and ASCII protocols. Master Control Relay for emergency shutdown. Two potentiometers for analog simulation. Heat dissipation 15.7 W. 20,000,000 mechanical relay cycles. EMC Directive 89/336/EEC compliant.
Technical Specifications
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Part Number | 1762-L24BWA |
| Product Line | MicroLogix 1200 |
| Input Power | 120 to 240 Volts AC |
| No. of Inputs | 14 (10 standard + 4 fast, 24VDC) |
| Input Circuit Type | 24VDC Sink/Source |
| No. of Outputs | 10 (Relay) |
| Output Circuit Type | Relay |
| Relay Contact Rating | 24-125VDC; 120-240VAC |
| Load Current | 10A minimum |
| Mechanical Cycles | 20,000,000 |
| Communication Port | 1 x 8-pin mini-DIN RS-232 |
| Supported Protocols | DH-485, DF1, Modbus Master/Slave, ASCII |
| Heat Dissipation | 15.7 W |
| Inrush Current (120V) | 25A for 8 ms |
| Inrush Current (240V) | 40A for 4 ms |
| Dimensions (H x W x D) | 90 x 110 x 87 mm (104 mm with DIN latch open) |
| Weight | 0.9 kg (2 pounds) |
| Operating Temperature | 0°C to +55°C |
| Mounting | DIN Rail or Panel Mount |
| Certifications | UL, c-UL, CE, EMC Directive 89/336/EEC |
| UPC | 10612598207210 |
| UNSPSC | 32151705 |
Installation Notes
Mount on DIN rail or panel using provided slots. Disconnect power before installing or removing expansion I/O modules to prevent electrical arcing and contact wear. Connect 120-240VAC supply at 47-63 Hz. Use 8-pin mini-DIN RS-232 port for programming and network communication. For networked applications, use external interface converters such as 1761-NET-AIC to multiplex the RS-232 port. Maintain 0°C to 55°C operating temperature.
Engineering Advantages
Compact all-in-one design integrates power supply, I/O, communication, and memory to save panel space. 14 DC inputs with sink/source flexibility simplify field wiring. 10 relay outputs handle both AC and DC loads. Master Control Relay enables emergency machine shutdown. Two potentiometers allow analog simulation without external hardware. Expansion I/O capability supports application growth.
FAQs
Q1: How many inputs and outputs does this controller have?
A1: 14 digital inputs (24VDC sink/source) and 10 relay outputs.
Q2: What communication protocols are supported?
A2: DH-485, DF1 Full/Half-duplex, DF1 Radio Modem, Modbus Master/Slave, and ASCII via the RS-232 port.
Q3: What mounting options are available?
A3: DIN rail or direct panel mounting using the provided slots.
