SDV541-S63

Yokogawa SDV541-S63 Output Module

In stock (12 units), ready to be shipped

  • Manufacturer: Yokogawa

  • Product No.: SDV541-S63

  • Product Type: Digital Output Module

  • Product Origin: SG

  • Payment:T/T, Western Union

  • Weight: 290g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

Yokogawa SDV541-S63 Digital Output Module

The Yokogawa SDV541-S63 delivers 24V DC output across 16 channels with 30ms response time.

Module Features

  • Brand Model: Yokogawa SDV541-S63 Digital Output Module
  • Output Channels: 16 channels with module isolation
  • Output Voltage: 24 V DC with 1V maximum drop
  • External Power: 24V DC, 3.4 A minimum capacity
  • Current Range: 35 mA min, 0.2 A max per channel
  • Response Time: 30 ms maximum output response
  • Voltage Protection: 2 kV AC withstand for 1 minute
  • Temperature Range: -20 to 70 °C operation

Technical Details

  • Current Consumption: 300 mA at 5V, 150 mA at 24V
  • Leak Current: 1.6 mA maximum at OFF status
  • Load Resistance: 120 to 685 Ω range
  • Total Current: 3.2 A maximum across all outputs
  • Module Weight: 0.29 kg to 0.31 kg variations
  • Output Format: Current source configuration
  • Module Type: Standard with no explosion protection
  • Connection Options: Pressure clamp, MIL cable, or AKB331/AKB651

Setup Guide

  • Connect to 24V DC external power with 3.4A capacity
  • Maintain load current between 35 mA and 0.2 A per channel
  • Ensure load resistance stays within 120-685 Ω range
  • Account for 1.6 mA maximum leak current in system design
  • Install in -20 to 70°C temperature environments

Package Contents

  • One SDV541-S63 Digital Output Module
  • Required mounting hardware and accessories
  • Secure protective packaging materials
  • Shipping via FedEx, UPS, or DHL services

Common Questions

  • How many output channels? 16 isolated output channels
  • What output voltage? 24V DC with 1V maximum drop
  • Response time speed? 30 milliseconds maximum
