  • AGS813-S10-2
1 3

AGS813-S10

Yokogawa AGS813-S10 Servo Control Module

In stock (12 units), ready to be shipped

  • Manufacturer: Yokogawa

  • Product No.: AGS813-S10

  • Product Type: I/O Module

  • Product Origin: SG

  • Payment:T/T, Western Union

  • Weight: 360g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

Yokogawa AGS813-S10 Servo Control Module

The Yokogawa AGS813-S10 is an isolated servo module for turbomachinery control systems. This module processes LVDT or voltage feedback signals and provides servo control outputs.

Technical Specifications

  • Brand & Model: Yokogawa AGS813-S10
  • Module Type: Servo Module (Isolated)
  • Scan Cycle: 5 ms
  • Power Consumption: Maximum 500 mA (5V DC)
  • Weight: Approximately 0.36 kg
  • Connection: Dedicated AKB337 series cable

Input Specifications

  • LVDT Inputs: 4 isolated channels (3/5/6 wire)
  • Excitation: 5Vrms at 2.8-3.2kHz
  • Voltage Inputs: 4 isolated channels, 1-5V DC
  • Digital Inputs: 2 isolated channels, 24V DC
  • Accuracy: ±1% for LVDT, ±4mV for voltage inputs

Output Specifications

  • Current Outputs: 2 isolated channels
  • Output Range: Selectable ±25mA or ±50mA
  • Accuracy: ±150μA (±25mA) or ±300μA (±50mA)
  • Dither Function: 0 to ±20% at 33Hz
  • Load Resistance: 270Ω (±25mA) or 100Ω (±50mA)

System Features

  • Isolation: 500V AC withstand voltage protection
  • External Power: +11.4 to +13.2V DC, 0.3A required
  • Circuit Detection: Open circuit detection available
  • Filtering: Collective filtering for stable signals

Installation & Connection

  • Connect using AKB337-M005, M007, or M010 cables
  • Provide stable external power supply 11.4-13.2V DC
  • Ensure proper isolation between different signal types
  • Install in appropriate control system enclosure

Frequently Asked Questions

  • What signals does it accept? LVDT or 1-5V DC position feedback.
  • What servo output does it provide? Selectable ±25mA or ±50mA control.
  • What is the scan time? Fast 5ms scan cycle.
