3BSE066495R1

PM860AK01 ABB Process Controller 3BSE066495R1

In stock (32 units), ready to be shipped

  • Manufacturer: ABB

  • Product No.: 3BSE066495R1

  • Product Type: Processor Unit

  • Product Origin: SE

  • Payment:T/T, Western Union

  • Weight: 1100g

  • Shipping port: Xiamen

  • Warranty: 12 months

30-Day Return Policy · 12-Month Warranty
  • Fast Delivery
  • 24/7 Support
  • Quality Assurance

Description

ABB PM860AK01 AC 800M Process Controller

The 3BSE066495R1 (PM860AK01) is an ABB AC 800M entry-level process controller. It provides reliable control for basic to medium automation tasks with essential connectivity. This unit features straightforward DIN rail mounting and is a cost-effective solution for standard applications.

Core Technical Specifications

  • Brand & Model: ABB PM860AK01 (3BSE066495R1)
  • CPU: MPC860 @ 48 MHz, 16 MB RAM (10.3 MB for application from 800xA 5.1 FP4)
  • Function: Standard, non-redundant process control.
  • Communication: 2x RJ45 Ethernet, 2x RS-232C serial ports.
  • Mounting: Easy slide & lock mechanism on DIN rail (TP830 base plate).
  • I/O Support: Supports S800 I/O via Modulebus and CEX-Bus (max 96 modules).
  • Power Supply: 24 V DC (19.2-30V), typical 4.32 W dissipation.

Physical Data & Certifications

  • Weight: 1100 grams (approximately 2.4 lbs).
  • Dimensions: 119 mm x 186 mm x 135 mm (W x H x D).
  • Key Feature: Unique hardware Ethernet address on the base plate for easy identification.
  • Certifications: CE, cULus (Class 1, Zone 2), RoHS, WEEE, marine (ABS, BV, DNV-GL, LR).
  • Operating Temperature: +5°C to +55°C.

Frequently Asked Questions

  • Q: Is this controller suitable for safety or redundant applications?
    A> No. The PM860AK01 is for single, non-redundant standard control. For redundancy, consider the PM858K02. For safety, consider the PM857 with an SM81x module.
  • Q: What software is required for configuration?
    A> It is configured using ABB's 800xA Control Builder. Enhanced memory availability requires version 5.1 FP4 or later.
  • Q: What is the main application of this controller?
    A> It is ideal for smaller control systems, standalone machines, or as a sub-system controller in larger plants where high availability or safety certification is not required.
