GE Genius I/O IC660BBA020 Analog Module 4 Input 2 Output

GE Genius I/O Analog I/O Module IC660BBA020

The GE Genius I/O IC660BBA020 is an analog input/output module for Genius network systems. It provides 4 analog inputs and 2 analog outputs with 12-bit resolution for precise process control applications.

Technical Specifications

• Brand & Model: GE Genius I/O IC660BBA020
• Module Type: Analog Input/Output Module
• Analog Inputs: 4 channels
• Input Signals: 0-10V DC, ±10V DC, ±5V DC, 0-5V DC, 4-20 mA
• Analog Outputs: 2 channels
• Output Signals: 0-10V DC, 0-5V DC, 4-20 mA (configurable)
• Resolution: 12-bit + sign
• Accuracy: ±0.2% typical, ±0.5% maximum of full scale
• Power Supply: 18-56 VDC (24/48 VDC block power)
• Protocol: Genius Protocol
• Isolation: 1500V block-to-block
• Heat Dissipation: 6 Watts
• Dimensions (H×W×D): 22.44 × 8.89 × 10.00 cm (8.83" × 3.50" × 3.94")
• Product Weight: 1.8 kg (4 lbs)
• Status Indicators: Unit OK, I/O Enabled LEDs

Key Features

• 4 high-precision analog input channels
• 2 configurable analog output channels
• 12-bit + sign resolution for accurate signal processing
• Wide input voltage range (18-56 VDC)
• Genius Protocol for reliable industrial communication
• 1500V isolation for safety and noise immunity
• Status LEDs for easy monitoring

Shipping Information

• 1x IC660BBA020 analog I/O module
• Approximate shipping weight: 2.2 kg (including packaging)
• Secure protective packaging
• Shipped via FedEx, UPS, or DHL

FAQ

• What analog signals can it handle?
  Inputs: 0-10V, ±10V, ±5V, 0-5V, 4-20mA. Outputs: 0-10V, 0-5V, 4-20mA.
• What is the Genius Protocol?
  A high-speed serial communication protocol developed by GE for industrial I/O systems.
• What is the module's resolution?
  12-bit plus sign bit, providing high precision for analog signal conversion.
