ABB IMHSS03 Precision Hydraulic Servo Module 0-10V 4-20mA Input

Stok ada (12 unit), sedia untuk dihantar

  • Manufacturer: ABB

  • Product No.: IMHSS03

  • Product Type: Hydraulic Servo Module

  • Product Origin: Sweden

  • Payment:T/T, Western Union

  • Weight: 1400g

  • Shipping port: Xiamen

  • Warranty: 12 months

Polisi Pemulangan 30 Hari · Jaminan 12 Bulan
  • Penghantaran Pantas
  • Sokongan 24/7
  • Jaminan Kualiti

Penerangan

Product Overview

The ABB IMHSS03 is a high-precision hydraulic servo module engineered for closed-loop motion control, valve positioning, and high-pressure fluid power regulation in advanced industrial automation environments. Designed for seamless integration into distributed control architectures, this module translates standard analog control commands into rapid, high-force hydraulic actuator movements.

Operating on a nominal 24 V DC power supply with a maximum current draw of 3 A, the IMHSS03 controls hydraulic pressures up to 200 bar (2900 psi) with sub-10 ms response times. Housed in a heavy-duty IP67-rated enclosure measuring 20.3 cm x 5.1 cm x 33.0 cm (8.0" x 2.0" x 13.0"), the unit has a net weight of 0.60 kg (1.25 lbs) and an estimated gross shipping weight of 1.40 kg (3.09 lbs).

Core Technical Advantages

  • High-Speed Hydraulic Response: Delivers rapid dynamic control with a system response time under 10 ms, ensuring precise real-time valve and cylinder positioning.
  • Dual Bus Communication: Features integrated EtherCAT and CANopen fieldbus interfaces for high-speed deterministic networking and continuous diagnostic monitoring.
  • Extreme Environmental Protection: Heavy-duty IP67-rated sealed enclosure guards sensitive internal electronic components against water immersion, fluid spray, and ambient dust contaminants.
  • Versatile Control Inputs: Accepts field-configurable 0–10 V voltage or 4–20 mA current loop analog control signals for flexible controller compatibility.

Technical Specifications

Parameter Specification Details
Brand / Manufacturer ABB
Part Number / Model IMHSS03
Product Description Hydraulic Servo Control Module
Operating Voltage / Max Current 24 V DC | 3 A (max)
Control Signal Input 0–10 V DC or 4–20 mA analog
System Response Time < 10 ms
Maximum Working Pressure 200 bar (2900 psi)
Position Feedback Type Analog Position Sensor Interface
Communication Interfaces EtherCAT, CANopen
Ingress Protection Rating IP67 Rated
Cooling Method / Operating Temp Natural Convection | -20 °C to +70 °C (-4 °F to +158 °F)
Module Dimensions (H x W x D) 33.0 cm x 5.1 cm x 20.3 cm (13.0" x 2.0" x 8.0")
Estimated Net / Shipping Weight Net Unit: 0.60 kg (1.25 lbs) | Gross Shipping: 1.40 kg (3.09 lbs)

Installation & Wiring Guidelines

  • Hydraulic Line Connection: Ensure all high-pressure hydraulic fittings are rated to at least 200 bar (2900 psi) and bleed residual air from the fluid manifold prior to applying servo power.
  • Power Supply Wiring: Connect a clean, regulated 24 V DC power source rated for minimum 3 A output capacity, keeping wire runs short to prevent excessive voltage drops.
  • Fieldbus Topology: Terminate industrial Ethernet / CANopen fieldbus lines with appropriate network termination resistors to maintain high-speed signal integrity.

Technical FAQs

Q1: What control input options are supported by the ABB IMHSS03 module?
A1: The module supports standard analog control inputs, configurable for either 0–10 V voltage or 4–20 mA current loop signals.

Q2: What maximum fluid pressure can the IMHSS03 handle?
A2: It is rated for a maximum operating pressure of 200 bar (2900 psi).

Q3: What fieldbus communication protocols are built into this hydraulic servo unit?
A3: The unit includes native EtherCAT and CANopen fieldbus communication interfaces.
