330905-00-05-10-11-00 | Bently Nevada Proximity Probe FluidLoc

The Bently Nevada 330905-00-05-10-11-00 is a 3300 NSv Proximity Probe with FluidLoc cable for industrial vibration monitoring. It features M10X1 threads with 1.0m FluidLoc cable and ClickLoc connector with protector.

Product Details

• Part Number: 330905-00-05-10-11-00
• Model: 3300 NSv Proximity Probe
• Manufacturer: Bently Nevada
• Condition: New Original, Factory Sealed
• Warranty: 12 Months
• Weight: 14-150 g (0.5-5.3 oz)

Configuration

• Thread Type: M10X1, without armor
• Unthreaded Length: 00 mm
• Case Length: 50 mm
• Cable Length: 1.0 meter (39 in)
• Connector: Miniature coaxial ClickLoc with connector protector, FluidLoc cable
• Approval: Not required (00)

Electrical Specifications

• DC Resistance: 4.2 ± 0.5 ohms at 1.0m
• Linear Range: 1.5 mm (60 mils) from 0.25 to 1.75 mm
• Recommended Gap: 1.0 mm (40 mils)
• Scale Factor: 7.87 V/mm (200 mV/mil) +12.5%/-20%
• Deviation: Less than ±0.06 mm (±2.3 mils)
• Output: -1 to -13 Vdc
• Frequency Response: 0-10 kHz: +0, -3 dB typical

Extension Cable

• DC Resistance: Center 0.220 Ω/m, Shield 0.066 Ω/m
• Capacitance: 69.9 pF/m typical

Mechanical Specifications

• Tip Material: Polyphenylene sulfide (PPS)
• Case Material: AISI 304 stainless steel
• Cable: 75 Ω coaxial, FEP insulated, FluidLoc
• Min Bend Radius: 25.4 mm (1.0 in)
• Seal: Viton O-ring

FAQs

• What is FluidLoc cable?
  FluidLoc provides enhanced resistance to fluids and chemicals compared to standard cable.
• What is the cable length?
  The 330905-00-05-10-11-00 has a 1.0 meter (39 in) FluidLoc cable.
• Does this probe have agency approvals?
  No, this configuration has no agency approvals (Option 00).
