SKU:CC-PAOH51
CC-PAOH51 Honeywell HART Analog Output Experion PKS
Manufacturer: Honeywell
Product No.: CC-PAOH51
Product Type: Output Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 350g
Shipping port: Xiamen
Warranty: 12 months
Teilen
- Schnelle Lieferung
- Rund-um-die-Uhr Unterstützung
- Qualitätssicherung
Beschreibung
Key features & benefits
- 16 HART-enabled analog output channels for precise 4-20mA control.
- Integrated HART modems enable remote diagnostics and device configuration.
- ±0.1% accuracy with 16-bit resolution for critical loop control.
- Supports redundant configuration with <10ms switchover.
- G3 conformal coating option (-176) protects against corrosive environments.
Technical specifications
- Brand & model: Honeywell CC-PAOH51 (51410070-175/176/275)
- Type: HART Analog Output Module
- Output channels: 16
- Output signal: 4-20mA (0-20mA, 0-10V selectable)
- Resolution: 16-bit
- Accuracy: ±0.1% of full scale
- Linearity: ±0.05% of full scale
- Maximum resistive load: 800 ohms at 24V supply
- Output ripple: <100mV peak-to-peak
- Response time: <80ms settle to 1%
- Power supply: 24V DC (18-30V DC)
- Power consumption: 4W max
- Isolation: 500V channel-to-channel, 1500V channel-to-system
- Operating temperature: 0 to +60°C
- Storage temperature: -40 to +85°C
- Humidity: 5-95% non-condensing
- Weight: 0.35kg
- Certifications: CE, UL, CSA, Class I Div 2 / Zone 2
Installation guide
- Mount CC-PAOH51 onto Series C I/O rack with compatible IOTA (CC-TAOX51 non-redundant or CC-TAOX61 redundant).
- Connect field wiring to termination assembly.
- Configure FAILOPT options: Hold Last Value, Shed Low (4mA), or Shed High (20mA).
- For redundant setups, install dual modules with <10ms switchover.
- Module supports hot-swap in redundant configuration.
FAQ
-
What is CC-PAOH51?
16-channel HART analog output module for Experion PKS Series C. Provides 4-20mA control with integrated HART diagnostics. Weight 0.35kg. -
Difference between -175 and -176 suffix?
-176 includes G3 conformal coating for protection against corrosive gases like H₂S. -175 is standard coating. -
Is external HART multiplexer required?
No. HART modems are integrated into each channel. Digital data passes through Series C I/O link.
