Allen-Bradley 2097-V33PR5-LM | 2 kW Single Axis Servo Drive

Allen-Bradley Kinetix 350 Single Axis Ethernet/IP Servo Drive 2097-V33PR5-LM

The Allen-Bradley 2097-V33PR5-LM is a single-axis servo drive from the Kinetix 350 series. It provides precise indexing motion control via Ethernet/IP connectivity. This drive supports a wide range of AC input voltages and includes integrated Safe Torque-Off functionality for operational safety.

Core Specifications

• Brand & Model: Allen-Bradley 2097-V33PR5-LM
• Series: Kinetix 350 Single Axis Ethernet/IP Drive
• Input Voltage: 80-132V AC (1-Phase), 80-264V AC (1/3-Phase)
• Input Frequency: 48–62 Hz
• Continuous Output Current: 8.0 A RMS / 11.3 A (0-Pk)
• Peak Output Current: 24.0 A RMS / 33.9 A (0-Pk)
• Continuous Power Output: 2.0 kW
• Control Power Backup: 20–26V DC
• Safe Torque-Off (STO): Yes

Electrical & Physical Details

• Nominal AC Input Current: 15.0 A RMS (120/240V 1-Phase), 8.7 A RMS (240V 3-Phase)
• Inrush Current (Peak): 1.15 A (120/240V), 2.3 A (240V)
• Control Backup Inrush: Max 30 A
• Dimensions: 9.37" x 7.29" x 4.1" (238 x 186.1 x 104.1 mm)
• Weight: 4.4 lbs (2.0 kg)
• Integrated EMC Filter: No

FAQ

• What is the difference between the Kinetix 300 and 350 series?
  The Kinetix 350 is an evolution, often offering enhanced performance and features for single-axis control compared to the broader Kinetix 300 family.
• Does this drive include a built-in EMC filter?
  No, the 2097-V33PR5-LM does not have an integrated AC line filter. External filtering may be required based on application needs.
• Can I use this drive for multi-axis coordination?
  This is a single-axis drive. For multi-axis coordinated motion, a different motion controller or multi-axis drive system is needed.
